Product Details:
|
Alloy: | 8011 | Temper: | O |
---|---|---|---|
Thickness: | 0.010-0.011mm | Width: | 150-1250mm |
Application: | Food Container Used On Plane,fast Food Utensile | ID.: | 75mm,150mm |
Other Requirement: | As Customers | ||
High Light: | colored aluminum foil,aluminum foil containers |
Aluminum Foil for Food--including food packaging and food container:
Product Name |
Application |
Alloy |
Temper |
Thickness |
Width |
Container Foil |
Food Container |
3003/8011 |
O/H22/ |
0.045mm |
150mm - |
Household Aluminum Foil |
Food packing |
1235/8011 |
O |
0.009mm |
150mm - |
Aluminum Foil for Packaging--wide application:
Product Name |
Application |
Alloy |
Temper |
Thickness |
Width |
Beer bottle mark Foil |
Beer bottle mark |
8011 |
O |
0.010mm |
150mm - |
Pharmaceutical Foil |
Packing for Medicine |
8011 |
H18/O |
0.018mm |
150mm - |
Package, converting Foil |
Soft packing |
8011 |
O |
0.006mm |
150mm - |
Cigarette Foil |
Packing for Cigarette |
1060/1070/ |
O/H14/ |
0.05mm |
5mm - |
Our mechanical property:
Foil Classification |
Thickness(mm) |
|
Thickness Tolerrance |
Width Tolerance |
|
|
|||||
Thin Gauge |
0.005 |
1235 8011 8079 |
±5% |
(200-1880)±1 |
|
0.006 |
|
||||
0.0065 |
|
||||
0.007 |
|
||||
0.008 |
|
||||
0.009 |
|
||||
|
Strengthen(Mpa) |
50-160 |
|
||
|
|||||
Elongation(%) |
0.5%-8% |
|
|||
|
|||||
Typical core I.D. |
Φ76.2 Φ152 |
|
|||
|
|||||
Typical Coil O.D. |
Φ300 Φ500 Φ1000 (selectable) |
|
|||
|
|||||
Trace Elements |
pb≤0.01 cd≤0.01 As≤0.01 |
|
|||
|
|||||
Wettability |
≥Class B |
|
|||
|
|||||
Pin no. (P/m²) |
according to custiomer's requirements and technical agreement |
|
|||
|
|||||
Light (L) |
according to custiomer's requirements and technical agreement |
|
|||
|
|||||
Coil Connector |
according to custiomer's requirements and technical agreement |
|
|||
|
|||||
Surface Quality |
1 even serface flatness 2 clean surface without corrosion,spots,wrinkles,scratches,light and dark lines,marks slots etc. 3 no light spots,marke,wheel mark and black line. 4 no yellow spots from the lubricatio oil burning and breaks on the surface of the final production. |
|
|||
|
|||||
|
|||||
Quality Outside |
No defects such as burring, cracks, telescoping, loosen coils, core out, arrow etc.. Welding firmly, foil section neat and clean. |
|
|||
|
Our mechanical property:
Temper |
Tensile Strength Rm(MPa) |
Erichsen(mm) |
Elongation(%) |
O |
80-110 |
6.0 |
20 |
H22 |
100-135 |
5.5 |
16 |
H24 |
115-145 |
5.0 |
12 |
H26 |
125-160 |
4.0 |
8 |
H18 |
160 |
- |
1 |
Our advantage
1. Since 1988, we have rich experience in this industry in China;
2. Good reputation in copper cable industry;
3. We have our own development department for new material research;
4. Good experience and cooperation with big client in the world;
5. With Certificate ISO9001-2008;
6. High performance cost ratio;
7. Fast delivery time;
8. Good communication skills, and good service and understandings for customers;.
