Huge Length And Width 2mm Aluminium Sheet For Automobile , High Speed Railway

Huge Length And Width 2mm Aluminium Sheet For Automobile , High Speed Railway
Huge Length And Width 2mm Aluminium Sheet For Automobile , High Speed Railway Huge Length And Width 2mm Aluminium Sheet For Automobile , High Speed Railway Huge Length And Width 2mm Aluminium Sheet For Automobile , High Speed Railway

Large Image :  Huge Length And Width 2mm Aluminium Sheet For Automobile , High Speed Railway

Product Details:
Place of Origin: China
Brand Name: Trumony Aluminum Limited
Certification: ISO9001, ASTM, JIS, GB, EN, ASTMB
Model Number: TR
Payment & Shipping Terms:
Minimum Order Quantity: 5 tons
Price: Negotiable
Packaging Details: Standard Export Packaging
Delivery Time: 30 workdays after confirming
Payment Terms: L/C, T/T
Supply Ability: 800,000 MT Per Year

Huge Length And Width 2mm Aluminium Sheet For Automobile , High Speed Railway

Description
Alloy Code: According To Request Temper: O ~ H112, T6~T7751
Thickness: 0.5~250 Mm Width: ≥ 1800 Mm
Length: ≥ 6000 Mm Surface Treatment: According To Request
Usage: Automobile, Ship, Airplane, High Speed Railway, Car Tank, Etc Color: According To Request
High Light:

aluminum alloy sheet

,

High Speed Railway alloy sheet metal

,

Width 2mm Aluminium Alloy Sheet


Huge Length And Width 2mm Aluminium Sheet For Automobile , High Speed Railway

Detailed Product Description
Color: Silver Technology: Hot Rolling
Surface Treatment: According to request Transport Package: Standard Export Packaging
Specification: Thickness: 0.5~250mm Temper: HO~H112/T6/T73/T76/T74/T651/T7351/T7651/T7451/T7751




This kind of product is mainly used to introduce 7000 series high strength aluminum products, who enjoy the advantages of high strength, good toughness, good corrosion resistance, good cutting performance and easy surface treatment etc.. The products will be mainly applied in the industries which require much higher strength and lighter weight like aerospace, rail transportation, tooling and safety protection. Products has been certified by AS9100 and other aerospace systems.



Mechanical Properties

Plate

Alloy Temper Typical Thickness Tensile Strength Rm(Mpa)

Yield Strength

Rp0.2(Mpa)

Elongation(%) Standard
7075 T651 6.0~225.0 570 495 10 SAE AMS 4045
7075 T7351 6.0~150.0 500 420 10 SAE AMS 4075
7475 T7651 6.0~50.0 510 435 10 SAE AMS 4089
7050 T7451 6.0~225.0 530 460 10 SAE AMS 4050
7050 T7651 6.0~100.0 550 480 10 SAE AMS 4201
7B50 T6151 6.0~50.0 600 550 12 -------
7B50 T7751 6.0~100.0 590 540 10 -------
7A55 T7751 6.0~50.0 635 605 10 -------



Sheet

Alloy Temper Typical Thickness Tensile Strength Rm(Mpa)

Yield Strength

Rp0.2(Mpa)

Elongation(%) Standard
7075 T6 0.5~6.0 580 500 12 SAE AMS-QQ-A-250/12
7075 T73 0.5~6.0 480 405 12 SAE AMS-QQ-A-250/12
7075 T76 0.5~6.0 490 410 12 SAE AMS-QQ-A-250/12
7475 T61 0.5~6.0 540 460 12 SAE AMS 4084
7475 T761 0.5~6.0 510 435 12 SAE AMS 4085
7050 T76 0.5~6.0 535 485 10 SAE AMS 4243



Specification



Plate

Alloy Temper Thickness(mm) Width(mm)
7075

T651

T7351

T7651

T7451

T7751

6~12 800~2900
7475
7050 12~250 800~3800
7B50
7A55



Sheet

Alloy Temper Thickness(mm) Width(mm)
7075 T6,T73,T76,T74 0.5-3.5 800~2600
7475
7050 3.5-6.0 800~2900
7B50



Chemical Composition

alloy Si Fe Cu Mn Mg Cr Zn Zr Ti Standard
7075 0.40 0.50 1.2-2.0 0.30 2.1-2.9 0.18-0.28 5.1-6.1 0.05 0.20 En573
7475 0.10 0.12 1.2-1.9 0.06 1.9-2.6 0.18-0.25 5.2-6.2 0.05 0.06
7050 0.12 0.15 2.0-2.6 0.10 1.9-2.6 0.04 5.7-6.7 0.08-0.15 0.06
7B50 0.12 0.15 1.8-2.6 0.10 2.0-2.8 0.04 6.0-7.0 0.08-0.16 0.10 -----
7A55 0.10 0.10 1.8-2.5 0.05 1.8-2.8 0.04 7.5-8.5 0.08-0.20 0.10-0.25 -----





Flat Aluminum Sheet T6 / T73 / T76 / T74 / T651 / T7351 / T7651 / T7451 / T7751 For Air Container

Commercial terms

Minimum Order Quantity: 5 metric tons
Price: negotiation
Payment Terms: T/T or LC
Supply Ability: 50,000 mt per year
Delivery Time: 30 working days after received your down payment
Packaging Details: Standard export packaging
