Product Details:
|
| Model: | T2/1F/T2 | Total Thickness: | 0.2-3.0mm |
|---|---|---|---|
| Width: | 600mm Max | Length: | 1500-2000mm |
| Application: | LED, Battery Cover Plate, Connector For Low-voltage Apparatus, Kitchenware Material, Building Decoration Material, Copper Door Plate,embossed Metal Plate | Feature: | Good Processing Performance |
| High Light: | 2000mm Length Steel Copper Strip,Kitchenware Steel Copper Strip,350MPa Steel Copper Cladding Strip |
||
Product name:Steel Copper Composite Material For LED / Battery Cover Plate / Kitchenware Material
Product description for Steel Copper Composite Material
The double layers steel copper cladding strip (based on steel) combines the excellent properties of the two matrix materials, which not only keeps the appearance of the copper decorative, but also keep higher strength, light weight, high heat capacity, good elasticity, oxidation resistance, low cost and etc. Base steel & copper alloy brand can be produced according to customer requirements. The secondary processing performance of steel copper composite material is good, which can realize bending, drilling, deep punch & other processing.
Product usage:
It is suitable for LED, battery cover plate, connector for low-voltage apparatus, kitchenware material, building decoration material, copper door plate,embossed metal plate, etc.
We can customize R&D and produce multilayer metal composite materials with different combinations and proportions,which can achieve 1-8 series aluminum alloys and copper,steel,stainless steel, titanium, nickel and other metal composites, we can develop aluminum-based, steel-based, copper based and other series of metal composite materials for customers.
At present, the company's leading products are copper-aluminum,steel-copper,aluminum-steel, aluminum-copper, aluminum-titanium, and other metal composite materials; product specifications include plate, strip, and foil series. Product specifications: (0.03-10) mm x (20 -1050) mm.
The production design has an annual output of 30,000 tons of composite materials. The main equipment is
2 1650 hot-dip continuous casting and rolling,1250mm,650mm2,215050/1650 cold rolling mills, 8 hood annealing furnaces, 2 continuous heating and annealing furnaces pull-bend straightening, Cross sliing machine, washing machine and other ancillary equipment.
Our products are widely used in new energy vehicle batteries, 5G mobile communications, kitchen utensils (IH rice cookers, high-conductivity stainless steel woks, etc.), photovoltaics, LEDs, electronics, and construction.
Specification for Steel Copper Composite Material
| Model | Specification | ||||
| T2/1F/T2 | Total Thickness(mm) | Width(mm) | Length(mm) | ||
| 0.2-3.0 | 600mm max | 1500-2000 | |||
| Mechanical property | |||||
| Tensile strength(MPa) | Elongation(%) | Peel strength(N/mm) | |||
| 350 minimum | 15 minimum | 12 | |||
First class testing equipment:
The laboratory is equipped with metallographic microscope, direct reading spectrometer, universal tensile sample machine, salt spray test box, transmission electron microscope, peel tester, hardness tester, atom probe and other equipment.
Production equipment:
650mm Rolling mill
Bell Type Annealing Furnace
1250mm Rolling Mill
Oxygen-free Hot-plating Continuous Casting and Rolling Production Line
