Internally Enhanced Round Aluminum Tubing 3003 / 3103 Threaded Aluminum Pipe

Internally Enhanced Round Aluminum Tubing 3003 / 3103 Threaded Aluminum Pipe
Internally Enhanced Round Aluminum Tubing 3003 / 3103 Threaded Aluminum Pipe Internally Enhanced Round Aluminum Tubing 3003 / 3103 Threaded Aluminum Pipe Internally Enhanced Round Aluminum Tubing 3003 / 3103 Threaded Aluminum Pipe

Large Image :  Internally Enhanced Round Aluminum Tubing 3003 / 3103 Threaded Aluminum Pipe

Product Details:
Place of Origin: China
Brand Name: Trumony
Certification: ISO 9001:2000,ISO/TS16949:2002
Model Number: TR-014
Payment & Shipping Terms:
Minimum Order Quantity: 3-5ton
Price: negotiable
Packaging Details: plywood case
Delivery Time: 15-20days
Supply Ability: 20000mts

Internally Enhanced Round Aluminum Tubing 3003 / 3103 Threaded Aluminum Pipe

Description
Material: 3000 Series Thickness: 0.45-0.8mm
O.D.: 6.35-9.52mm Function: Increase Heat Transfer Rate,decrease Material Cost
Application: Evaporator, Condenser, Connection Tube
High Light:

round aluminum tubing

,

oval aluminum tubing

3003 / 3103 Internally Enhanced Round Tube / Aluminum Inner Grooved Tube





Product Description:

The Aluminum Inner Grooved Tube is following a helical pattern and have been optimized to improve heat transfer. The improvement in heat transfer coefficient of the tube is two times what can be achieved with
traditional smooth bore tubes3. This increased efficiency can help achieve a more compact design of the heat exchangers and a reduction in refrigerant load. different grooves depth and geometry satisfy the specific regional requirements and refrigerants in use.



Parameter for Aluminum Inner Grooved Tube

Specification bottom wall thickness Tooth height Tooth number Helix Angle Rib-top Angle g/m
φ7mm 0.4-0.5 0.05-0.18 40-50 18° 50° 28+/-3
φ9.52mm 0.45-0.55 0.05-0.18 45-55 18° 50° 45+/-3
φ7.94mm 0.4-0.5 0.05-0.18 40-50 18° 50° 40+/-3



The parameters in above form can also be adjusted as per customer's request.
Tensile:120MPa min
Elongation:35% min
Expanding:40% min
Density:2.7



Application:Air-conditioner heat exchanger system



Product feature:
1. Light-weight
2. Good thermal conductivity properties and electrical conductivity
3. Good corrosion resistance
4. Good forming and bending properties
5. High recycling value
6. Small deviation range
7. High surface quality



Production time:15-20days



Internally Enhanced Round Aluminum Tubing 3003 / 3103 Threaded Aluminum Pipe 0
