3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm

Good quality Aluminium Strips for sales
Good quality Aluminium Strips for sales
Price is good, delivery time is quick. I’m so impressed by your products which all of them are in a high quality. Wish your business prosperous.

—— Peter

Thanks for your time Tracy.I have learned positive things because of you,You are great person.

—— Lilla

Thank you very much Tracy,You are always great.

—— Salmoon

Trumony firması ile 2006 senesinde tanıştık. İlk tanışmamızda firmanın daha yeni kurulduğunu, genç ve dinamik insanlar olduğunu fark ettik. İlk günden kazandığımız güven duygusu 13 sene sonunda gördük ki bizi yanıltmamış. Profesyonel yönetim kadrosu ve ekibi ile yurtdışında rastlanabilecek firmalardan biri olan Trumony firması Uzak Doğu'nun Alüminy

—— Murat Gunes

I'm Online Chat Now

3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm

China 3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm supplier
3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm supplier 3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm supplier 3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm supplier 3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm supplier

Large Image :  3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm

Product Details:

Place of Origin: China
Brand Name: Trumony
Certification: TS16949 ISO9001 GB ASTM
Model Number: 3003

Payment & Shipping Terms:

Minimum Order Quantity: 5 tons
Price: $ 2500-4000 / ton
Packaging Details: Wooden Pallets and Boxes
Delivery Time: 35 days
Payment Terms: L/C, T/T
Supply Ability: 100,000 tons / year
Contact Now
Detailed Product Description
Temper: H14 Specification: As Customize
Transport Package: Wooden, As Customize Application: Automotive Condenser
Common Specification: (0.06-0.14)*(16-35)mm

4343 H14 Aluminum Foil with High Quality for Automotive Condenser



1.Introduction



As aluminum reserves in the crust is very rich, It has more advantages over other metals. Aluminum in the future will still have a wide range of applications, for example, the car manufacturers are currently exploring the use of aluminum instead of steel, and make the car lighter. With the progress of technology, aluminum products not only in the aerospace, transportation, electronic power, construction and other traditional applications but also continue to grow rapidly in the new areas.



3003 aluminum is the most widely used a rust-proof aluminum, the strength of this alloy is not high.It's advantages are low plasticity, good corrosion resistance and good weldability, etc. So it is widly used for the fins of automobile air conditioner condenser.



2.Metal Content(3003)



Si:0.60

Fe:0.70

Cu:0.05-0.20
Mn:1.0-1.5
Mg: NO
Zn:0.10
Ti: NO

Al: Remainder
Other Metals per ≤0.05 total ≤0.15



Alloy NO. Si Fe Cu Mn Mg Cr Zn Ti Other Al
1050 0.25 0.4 0.05 0.05 0.05   0.05 0.03 0.03 ≥99.5
3003 0.6 0.7 0.05-0.2 1.0-1.5     0.1   0.05 Remainder
4047 11.0-13.0 0.8 0.3 0.15 0.1   0.2     Remainder
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 0.1     Remainder
6061 0.4-0.8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 0.25 0.15   Remainder
7075 0.4 0.5 1.2-2.0 0.3 2.1-2.9 0.18-0.28 5.1-6.1 0.2   Remainder



Alloy Code temper

Tensile Strength

Rm(MPa)

Yield Strength Rp0.2(Mpa)

Extend Ratio

A50(%)

TR-010,TR-020,TR-030,TR-040,TR-050,TR-110,TR-310,TR-116,TR-316,TR-111,TR-313,TR-121,TR-131,TR-141,TR-150,TR-151,TR-156 Etc. O 95-135* ≥35* ≥15*
H14 140-185 ≥125 ≥1.5
H24 140-185 ≥125 ≥3.0
H16 185-225 ≥160 ≥1.0
H18 ≥185 - ≥0.5
TR-166 Etc.tube material H24 185-235 ≥150 ≥8

TR-116,TR-316 Etc.tube

material

H14 140-185 ≥125 ≥3
H24 140-185 ≥125 ≥8



3.The flow chart

3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm



4.Company



Trumony Aluminum Limited is committed to providing clean aluminum material solution to the market. 'Through the discovery and creation, to bring value to customers' is the company philosophy. A manufacturer of aluminum materials with many years' experience, it was established in 2006. Through years of developing, we have supplied products to many large companies with different series of materials. Now we are widely engaged in transportation, heat exchange, cable, packaging, construction, electronics, environmental protection and other fields, Apart from our current production, we are also actively developing new aluminum materials and searching for customers solutions which is best suited for different industries to meet the precise needs of customers.



If you have the need about slitting, cutting and deep-producing, you can contact us.

Hope we can build the relationship in the future.
Good luck!

3003 H14 Aluminum Foil For Automotive Condenser , Thickness 0.06-0.14mm
