8011 Heat Exchanger Aluminum Foil , Aluminium Foil Rolls For HVAC System

8011 Heat Exchanger Aluminum Foil , Aluminium Foil Rolls For HVAC System
8011 Heat Exchanger Aluminum Foil , Aluminium Foil Rolls For HVAC System 8011 Heat Exchanger Aluminum Foil , Aluminium Foil Rolls For HVAC System 8011 Heat Exchanger Aluminum Foil , Aluminium Foil Rolls For HVAC System

Large Image :  8011 Heat Exchanger Aluminum Foil , Aluminium Foil Rolls For HVAC System

Product Details:
Place of Origin: China
Brand Name: Trumony
Certification: TS16949-2008
Payment & Shipping Terms:
Minimum Order Quantity: 5 Tons
Price: Negotiable
Packaging Details: Standard Strong Export Package
Delivery Time: 30 Working days
Payment Terms: L/C, T/T
Supply Ability: 800,000 Per Year

8011 Heat Exchanger Aluminum Foil , Aluminium Foil Rolls For HVAC System

Description
Alloy: 8006,8011 Thickness: 0.08-0.2mm
Width: 60-1440mm Colour: Gold , Blue
Inside Diameter: 75mm ,150mm , 200mm , 300mm Temper: HO , H22 , H24 , H26
Surface Treatment: Coated
High Light:

industrial aluminium foil

,

thermal transfer foil



8011 Epoxy / Hydrophilic Coated Aluminum Foil for HVAC System



Description:

Specifications of Aluminum :


1 . Grade

1000 Series: 1050 1060 1070 1100 1200 1235 etc
3000 Series: 3003 3004 3005 3102 3104 3105 3A21 etc.
5000 Series: 5005 5052 5083 5086 5154 5182 5251 5754 etc.
6000 Series: 6061 6063 6082 6A02 etc.
7000 Series: 7050 7075 7475 etc.
8000 Series: 8006 8011 8079 etc.


2 . Length:  As per customer's request


3 . Temper: all tempers, H1X, H2X, H3X, O, HXXX


4 . Continuous casting and hot rolled both available



Mechanical Performance ( For Reference Only )





Temper





Tensile Strength

Rm(MPa)

Yield Strength Rp0.2(Mpa)

Extend Ratio

A50(%)


O



80- 110



20



6.0



H22



100 - 135



16



5.5



H24


115 -145 12 5.0


H26



125 - 160


8 4.0


H18


160 1 -





Hydrophilic Foil Coating Layer Performance



S/N


Item Technical data


1


Film Thickness 1.0-2.0um ( one  side average thickness)
2 Hydrophilicity

Primary contact angle? o

Continuous contact angle? 20o

3 Adherencce Strength

Erichsen test result ( pressed depth 5mm ), no peeling off.

Gridding test (100 / 100 ) : No separating


4


Corrosion Resistance Salt & Spray test ( 72 hours ) : R . N ? 9.5


5


Alkai resistance Dipped in 20o% Na OH under 20oC for 3 minutes, absolutely no blister


6


Impregnant resistance Sample weight loss ? 1 %
7 Heat resistance

Under 200oC keep 5 minutes, performance and colo unchanged

Under 300oC keep 5 minutes, coating film become a bit yellow


8


Oil proof 24 Hours, no blister on the coating layer


9


Coating film odor  No strange odor


10


Abrasion to mold Same as ordinary aluminium foil



Application:

Heat exchanger of wind energy, electronic industry, nuclear energy, petroleum tube, shipping industry, etc

Package:

Standard Export wooden Case/Pallet

Characteristics:
Strong anti-corrosion;
Salt spray test: 1)epoxy coated aluminum foil:500 Hours,class 8 in PH<7;
                        2)hydrophilic aluminum foil:500 Hours,class 9.5 in PH=7.


8011 Heat Exchanger Aluminum Foil , Aluminium Foil Rolls For HVAC System 0
