Thick Aluminum Roof Coil Core Alloy 1060 , 3003 , 5052 Corrosion Resistance

China Thick Aluminum Roof Coil Core Alloy 1060 , 3003 , 5052 Corrosion Resistance supplier
Thick Aluminum Roof Coil Core Alloy 1060 , 3003 , 5052 Corrosion Resistance supplier Thick Aluminum Roof Coil Core Alloy 1060 , 3003 , 5052 Corrosion Resistance supplier

Large Image :  Thick Aluminum Roof Coil Core Alloy 1060 , 3003 , 5052 Corrosion Resistance

Product Details:

Place of Origin: China
Brand Name: Trumony
Certification: TS16949-2008
Model Number: TR-141

Payment & Shipping Terms:

Minimum Order Quantity: 5 metric tons
Price: negotiation
Packaging Details: Standard export packaging
Delivery Time: 30 working days after received your down payment
Payment Terms: T/T or LC
Supply Ability: 100,000 mt per year
Contact Now
Detailed Product Description
Core Alloy: 1060, 3003, 5052 Etc Cladding Alloy: 4343, 4045, 7072, 5052 Etc
Cladding Rate: 4%-18% Thickness: 0.2-3.0mm
Width: 12 - 1250mm (max) Temper: HO, H14 Etc
I. D.: 150mm, 200mm, 300mm, 400mm, 500mm Normal O. D.: 900-1450mm

1060, 3003, 5052

1. Chemical composition of cladding material, core material for welding heat exchanger

(1) Cladding Material


AlloySiFeCuMnMgZnZrTicode
43436.8-8.20.80.250.10.20.051
4343+1%Zn6.8-8.20.80.250.10.5-1.50.052
40459.0-11.00.80.30.050.20.23
4045+1%Zn9.0-11.00.80.30.050.5-1.50.24
40049.0-10.50.80.250.11.0-2.00.20.25
70720.70.10.10.10.8-1.36
50050.30.70.20.20.5-1.10.5-1.00.037


(2) Core Material


AlloySiFeCuMnMgZnZrTicode
30030.60.70.05-0.201.0-1.50.10.050.031
3003+1%Zn0.60.70.05-0.201.0-1.50.5-1.500.050.052
3003+1.5%Zn0.60.70.05-0.201.0-1.51.0-2.00.050.053
3003+1.5%Zn+Zr0.5-1.00.70.05-0.201.0-1.61.0-2.00.05-0.2-4
3003+0.5%Cu0.60.70.30-0.701.0-1.50.100.050.15

3005

0.60.70.20-0.401.0-1.50.20-0.600.250.016


2. Mechanical properties of aluminum alloy and composite-material for welding heat exchanger


Alloy Codetemper

Tensile Strength
Rm(MPa)

Yield Strength Rp0.2(Mpa)

Extend Ratio
A50(%)

TR-010,TR-020,TR-030,TR-040,TR-050,TR-110,TR-310,TR-116,TR-316,TR-111,TR-313,TR-121,TR-131,TR-141,TR-150,TR-151,TR-156 Etc.O95-135*≥35*≥15*
H14140-185≥125≥1.5
H24140-185≥125≥3.0
H16185-225≥160≥1.0
H18≥185-≥0.5
TR-166 Etc.tube materialH24185-235≥150≥8
TR-116,TR-316 Etc.tube materialH14140-185≥125≥3
H24140-185≥125≥8



Remark:“*”in the above file means tensile strength shall be 120-150Mpa,yield strength shall be ≥45Mpa,and elongation shall be ≥20% if the material of TR-050,TR-150,TR-151,TR-156 etc. with temper O contain Cu..
Additional: We can produce special specifications according to customer’s requests.

3. Production capability

 Width(mm)Thickness(mm)Length(mm)Inside Diameters(mm)
Sheet500-10700.5-5.0500-2500-
Strip12-10700.2-3.0-150,200,300,400,500
Foil12-10700.05-0.2-150,200,300,400,500



Composite ratio4-18%(per side)



Percent Clad(per side)4-8%> 8-18%
Cladding tolerance±1.5%±2.0%


4. Our advantage

(1). Good reputation in Aluminum and Copper Areas;

(2). We have gained rich experience from 1988  in this industry in China;

(3). New material research is focused by our own development department;

(4). Our processing starts from aluminum ingot,so we can control the quality as well;

(5). Good experience and cooperation with giant clients in the world;

(6). Fast delivery time;

(7). High performance cost ratio;

(8). With Certificate ISO14001, TS16949
(9). Good service, and good communication skills and understandings for customers;

Thick Aluminum Roof Coil Core Alloy 1060 , 3003 , 5052 Corrosion Resistance
