0.08mm Thick Aluminum Heat Transfer Fin Foil For Auto Radiator Alloy 3003

0.08mm Thick Aluminum Heat Transfer Fin Foil For Auto Radiator Alloy 3003

    • 0.08mm Thick Aluminum Heat Transfer Fin Foil For Auto Radiator Alloy 3003
    • 0.08mm Thick Aluminum Heat Transfer Fin Foil For Auto Radiator Alloy 3003
  • 0.08mm Thick Aluminum Heat Transfer Fin Foil For Auto Radiator Alloy 3003

    Product Details:

    Place of Origin: China
    Brand Name: Trumony
    Certification: TS16949-2008
    Model Number: TR-3003

    Payment & Shipping Terms:

    Minimum Order Quantity: 5Ton
    Price: Negociation
    Packaging Details: Standard Export Packaging
    Delivery Time: 30 working days
    Payment Terms: L/C, T/T
    Supply Ability: 100,00Ton Per Year
    Contact Now
    Detailed Product Description
    Thickness: 0.08mm Width: 16mm
    Alloy: AA3003 Temper: H14
    Inside Diameter: 200mm
    High Light:

    aluminium foil rolls

    ,

    thermal transfer foil

    1. Company representation

    Our company was established in 2006 and mass production began in Jan.2007. With ISO 9001:2000 and ISO/TS16949.2002 certificated , we are one of the global leading and most specialized suppliers of heat exchanger materials for automobile, HVAC and industrial cooling tower, Our designed annual capacity is 80,000MT in the first stage.



    2. Application

    Can be used in a variety of heat exchange constructions where the basic function is to efficiently transfer heat. Also this fin foil can be used for evaporator and condenser in most residential, automotive ,and commercial air conditioning units and in humidifiers and etc.



    3. Discreption  of our products

    Chemical composition of core material,cladding material about aluminum alloy and composite-material for welding heat exchanger

    Material Chemical composition

    Alloy Si Fe Cu Mn Mg Zn Zr Ti code
    3003 0.6 0.7 0.05-0.20 1.0-1.5 0.1 0.05 0.03 1



    Main mechanical of aluminum alloy and composite-material for welding heat exchanger

    Alloy Code temper

    Tensile Strength

    Rm(MPa)

    Yield Strength Rp0.2(Mpa)

    Extend Ratio

    A50(%)

    AA 3003 O 95-135* ≥35* ≥15*

    Remark:“*”in the above file means the tensile strength will be 120-150Mpa,yield strength will be ≥45Mpa,and elongation will be ≥20% if the material of TR-050,TR-150,TR-151,TR-156 etc. with temper O contain Cu..

    Additional: We can produce special specification according to customer’s request.



    Composite ratio 4-18%(per side)



    4. FAQ



    1. Are you a manufacturer of aluminum raw material ?

     Yes, we are. We have our own factory.



    2. What information shall I let you know if I want offer ?

    (1),The Temper , Alloy , Thickness and Width , if you to give us the usage of products, it is better for us to understanding.

    (2),It will be better if you can show us the technical data sheet or pictures. Samples will be best for clarifying. If not, we will recommend relevant products with details for reference. We usually produce goods based on customer's samples or based on customer's picturers, sizes etc.



    5. Our advantage




    1. Since 2004, we have rich experience in this industry in China;
    2. Good reputation in household foil areas;
    3. We start our productions from aluminum ingot,so we can control the quality as well;
    4. We have our own development department for new material research;
    5. Good experience and cooperation with big client in the world;
    6. With Certificate ISO9001-2008;
    7. High performance cost ratio;
    8. Fast delivery time;
    9. Customized orders available;
    10. Good communication skills, and good service and understandings for customers;.
