Product Details:
|
| Thickness: | 0.08mm | Width: | 26mm Or As Customer Request |
|---|---|---|---|
| Temper: | H16 | Surface: | Unclad |
| Feature: | Corrosion Resistance | ||
| High Light: | aluminium foil rolls,thermal transfer foil |
||
1.Company Introduction
We insist on the market-oriented and customer-centric principle and pursue the benign interaction, faith cooperation and win-win policy with customers and suppliers, so as to realize the development and growth of our company.
2.High Performance-Price Ratio
We have lower operation cost but well management ensures us reliable quality , we now are offering what we have saved to all our loyal customers
3.Experienced R&D team
We have our own R&D center which provides our related departments with newest & updated technique. We are also willing to offer our customers help to meet the change of HVAC and engine cooling industry.
4.Products Discreption
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Zr | Ti | code |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | － | 0.1 | 0.05 | 0.03 | 1 |
| 3003+1%Zn | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | － | 0.5-1.50 | 0.05 | 0.05 | 2 |
| 3003+1.5%Zn | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | － | 1.0-2.0 | 0.05 | 0.05 | 3 |
| 3003+1.5%Zn+Zr | 0.5-1.0 | 0.7 | 0.05-0.20 | 1.0-1.6 | － | 1.0-2.0 | 0.05-0.2 | - | 4 |
| 3003+0.5%Cu | 0.6 | 0.7 | 0.30-0.70 | 1.0-1.5 | － | 0.10 | 0.05 | 0.1 | 5 |
| 3005 | 0.6 | 0.7 | 0.20-0.40 | 1.0-1.5 | 0.20-0.60 | 0.25 | － | 0.01 | 6 |
| Alloy Code | temper |
Tensile Strength Rm(MPa) |
Yield Strength Rp0.2(Mpa) |
Extend Ratio A50(%) |
| TR-010,TR-020,TR-030,TR-040,TR-050,TR-110,TR-310,TR-116,TR-316,TR-111,TR-313,TR-121,TR-131,TR-141,TR-150,TR-151,TR-156 Etc. | O | 95-135* | ≥35* | ≥15* |
| H14 | 140-185 | ≥125 | ≥1.5 | |
| H24 | 140-185 | ≥125 | ≥3.0 | |
| H16 | 185-225 | ≥160 | ≥1.0 | |
| H18 | ≥185 | - | ≥0.5 | |
| TR-166 Etc.tube material | H24 | 185-235 | ≥150 | ≥8 |
| TR-116,TR-316 Etc.tube material | H14 | 140-185 | ≥125 | ≥3 |
| H24 | 140-185 | ≥125 | ≥8 |
Remark:“*”in the above file means the tensile strength will be 120-150Mpa,yield strength will be ≥45Mpa,and elongation will be ≥20% if the material of TR-050,TR-150,TR-151,TR-156 etc. with temper O contain Cu..
Additional: We can produce special specification according to customer’s request.
Produce capability
| Width(mm) | Thickness(mm) | Length(mm) | Inside Diameters(mm) |
| Foil | 12-1070 | 0.05-0.2 | - | 150,200,300,400,500 |
5.Our advantage
1. Good reputation in Aluminum and Copper Areas;
2. We start our productions from aluminum ingot,so we can control the quality as well;
3. With Certificate TS16949, ISO14001 and OHSAS 18001;
4. Good communication skills, and good service and understandings for customers;.
5.Since 1988, we have rich experience in this industry in China;
