0.16 X 100 Mm 1100 HO Aluminium Air Cooling Fin Foil For Auto Air Conditioning

0.16 X 100 Mm 1100 HO Aluminium Air Cooling Fin Foil For Auto Air Conditioning

0.16 X 100 Mm 1100 HO Aluminium Air Cooling Fin Foil For Auto Air Conditioning

Product Details:

Place of Origin: China
Brand Name: Trumony
Certification: ISO9001-2008
Model Number: TR-FR200

Payment & Shipping Terms:

Minimum Order Quantity: 5 metric tons
Price: negotiation
Packaging Details: Standard export packaging
Delivery Time: 30 working days after received your down payment
Payment Terms: T/T or LC
Supply Ability: 50,000 mt per year
Contact Now
Detailed Product Description
Alloy: 1100 Temper: HO
Thickness: 0.16mm Width: 100mm
I.D.: 75mm O.D.: 750-850mm
Rm(MPa): 75-105 A50(%): 15 Min
Cup Drawing Value(mm): 5.5 Min Other Requirements: According To Customers' Requests

0.16 x 100mm 1100 HO Aluminium Air Cooling Fin Foil for Automotive Air Conditioning



1. Description of our production


Our chemical composition:




Si Fe Cu Mn Mg Zn Cr Ti code
8011 0.5-0.9 0.6-1.0 0.1 0.2 0.05 0.1 0.05 0.08 1
1100 0.95 0.05-0.2 0.05 -- 2
1200 1.00 0.05 0.05 0.05 3


Our mechanical property:



Tensile Strength


Erichsen(mm) Elongation(%)
O 80-110 6.0 20
H22 100-135 5.5 16
H24 115-145 5.0 12
H26 125-160 4.0 8
H18 160 - 1


Produce capability:


Product Width(mm) Thickness(mm) O.D.(mm) Inside Diameters(mm)
Fin stock 60-1440 0.08-0.2 400-1400 75,150,200,300,400



2. Our advantage


1. Since 1988, we have rich experience in this industry in China;


2. Good reputation in Aluminum and Copper Areas;


3. We start our productions from aluminum ingot,so we can control the quality as well;


4. We have our own development department for new material research;


5. Good experience and cooperation with big client in the world;


6. With Certificate ISO9001-2008;


7. High performance cost ratio;


8. Fast delivery time;


9. Good communication skills, and good service and understandings for customers;.



3. Application:


Aluminum fin foil can be used in a variety of heat exchange constructions where the basic function is to efficiently transfer heat. Also this fin foil can be used for evaporator and condenser in most residential, automotive, and commercial air conditioning units. In addition, this foils are used in humidifiers, dehumidifiers, baseboard space heaters of various types, and other equipment.



4. FAQ:


1, Q: Are you manufacturer?

A: Yes, we are established in 2003. As a manufacturer our customers are welcome to visit our factory.


2, Q: Do you accept customized orders?

A: Yes, we do. Your customized orders are always welcomed. Please kindly offer us your technical perfrmances or samples so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.


3. Q: How can I get one quotation faster?

A: Pls offer details about your demands as more as possible,insulation thickness,over diameter,nominal voltage,working temperature,color,quantity,application,etc.


4, Q: What's your MOQ?

A: Normally 1 metric tons are requested as the minimum order quantity on our side.


5, Q: What's your payment term?

A: 30% deposit in advance via T/T,balance before shipment.
