3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management

Certification
China Trumony Aluminum Limited certification
China Trumony Aluminum Limited certification
Customer Reviews
We sincerely thank you for welcoming us and treating us kindly when we visited the Trumony factory yesterday. Trumony's factories and facilities have given us confidence, and we believe that our company and Trumony will work together on more projects and develop together

—— KIM

Price is good, delivery time is quick. I’m so impressed by your products which all of them are in a high quality. Wish your business prosperous.

—— Peter

Thanks for your time Tracy.I have learned positive things because of you,You are great person.

—— Lilla

Thank you very much Tracy,You are always great.

—— Salmoon

Trumony firması ile 2006 senesinde tanıştık. İlk tanışmamızda firmanın daha yeni kurulduğunu, genç ve dinamik insanlar olduğunu fark ettik. İlk günden kazandığımız güven duygusu 13 sene sonunda gördük ki bizi yanıltmamış. Profesyonel yönetim kadrosu ve ekibi ile yurtdışında rastlanabilecek firmalardan biri olan Trumony firması Uzak Doğu'nun Alüminy

—— Murat Gunes

As you have said the economy after the lockdown go on slowly. We have no idea which will be the future. Many economists say that the world start a new changed process. The economy as we know it will be not the same in the future.I think it too.In the meanwhile we only can do our best.Thanks for your support.Every efforts we do, now more than ever

—— Monica Belfiore

I'm Online Chat Now

3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management

3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management
3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management
3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management 3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management 3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management

Large Image :  3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management

Product Details:
Place of Origin: China
Brand Name: Trumony
Certification: IATF/ISO/SGS
Payment & Shipping Terms:
Minimum Order Quantity: Sample trial can be arranged
Price: negotiable
Packaging Details: Ply-wood box specialized for export
Delivery Time: 30days including tooling time
Payment Terms: T/T, L/C, D/P, D/A
Supply Ability: 100000 tons yearly

3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management

Description
Alloy: 3003,3102,1100,1050 Temper: O,F,H111,H112
Shape: Serpentine/Bent Surface: Coating/Insulation
Thickness: 1-10mm Width: 8-200mm
Length: According To Customers' Requirement Applications: Battery Pack Thermal Management
Process: Bending/Coating/Welding
High Light:

Serpentine Aluminum Extruded Tube

,

3003 Aluminum Extruded Tube

,

f temper aluminum extrusion tube

3003 Serpentine Aluminum Extruded Tube For Battery Pack Thermal Management




1. Product Introduction:

The Serpentine Aluminium Extruded Tubes are further processed from the micro-channel aluminum tubes,which are unique tubes developed with highly refined manufacturing quality.The tube port and tube size can be customized according to customers' design.

We can achieve more efficient heat transfer  by making the large internal surface area and hence are widely used in highly effective heat exchangers.



Based on the recent few years' supplying experience,we could offer R&D recommendation,tooling design service together with the sample supply for prototype manufacturing. We have combined our supply chain with brazing technology,extrusion technology,CNC processing,painting,welding etc thus ensured our clients with one stop sourcing for short sample delivery time and mass production cost efficiency.



Relying on our strong design team and project management team,as well as the production support with many customers in China and oversea countries,we have accumulated first-hand experience,which will surely make your project fall into the ground most quickly and reliably.It has always been our mission that using materials to make technology come true.


2. The Aluminium Multi Port Extrusion (MPE) or microchannel tube is unique tube developed with the highest manufacturing quality and is characterized by the following properties:

1) Light weight
2) Excellent conductor of heat and electricity
3) High corrosion resistance,the surface can be coated
4) High recycling value
5) High surface quality
6) High pressure resistance

7)High heat transfer and high touching area with battery to increase the heat exchange




3. Commonly used material chemical composition

No. Alloy Si Fe Cu Mn Mg Cr Zn V Ti
1 1050 ≤0.25 ≤0.40 ≤0.05 ≤0.05 ≤0.05 --- ≤0.05 ≤0.05 ≤0.03
2 1100 ≤0.95(Si+Fe) 0.05-0.20 ≤0.05 --- --- ≤0.10 --- ---
3 3102 ≤0.40 ≤0.70 ≤0.10 0.05-0.40 --- --- ≤0.30 --- ≤0.10
4 3003 ≤0.15 ≤0.15 ≤0.01 0.90-1.10 ≤0.03 ≤0.03 ≤0.05 ≤0.05 ≤0.05


4. Supply state and mechanical properties

Alloy Temper Tensile Strength Yield Strength Elongation

1050

O/F/H111/H112 ≥65MPa ≥20MPa ≥25%
1100 O/F/H111/H112 ≥75MPa ≥20MPa ≥25%
3102 O/F/H111/H112 ≥75MPa ≥20MPa ≥25%
3003 O/F/H111/H112 ≥75MPa ≥20MPa ≥25%



5. Application:New Energy Vehicles Battery Pack Cooling



6. FAQ:

Q: Are you a trading company or manufacturer?
A:Yes,we are a factory with more than 10 years history in this industry.

Q: What is your terms of payment ?
A: Normally 30% TT in advance, balance paid before shipment.

Q: How long does it take for samples and mass production?
A: Usually it will take 15-20 days for new moulds and free samples (within 5 kg),;
after confirmation, 25-30 days for mass production.

Q:OEM/ODM available?
A:Yes,we can!

Q:Could you provide sample?
A:Yes, We are honored to offer you samples for quality check.

Q:Is sample order accepted?
A:Yes,we accept sample order and we can provide design service!
