In 2024, the global data center cooling market exceeded $20 billion and is projected to reach $48 billion by 2030.
The single driver behind this growth is the explosive rise in AI server power consumption.
Traditional server power: 300–500 W
NVIDIA H100 GPU server: 10,000 W+ per unit
Air cooling limit: ~1,000 W/U
Liquid cooling capacity: 5,000–20,000 W/U easily handled
Air cooling has reached its physical limit. Liquid cold plates (LCPs) have become the standard cooling solution for high-performance servers.
CNC machining of liquid cold plates is among the most challenging components Trumony has mastered over 19 years.
This article systematically breaks down CNC machining logic for server liquid cold plates — from structural design and material selection to processing challenges and quality control.
1. What Is a Liquid Cold Plate & How It Works
A Liquid Cold Plate (LCP) is a metal plate with internal flow channels. Coolant (water, water‑glycol, or specialty fluid) circulates internally to remove heat from CPUs, GPUs, power modules, and other heat sources.
Two Core Performance Metrics
Metric
Definition
Typical Target (High‑End AI Servers)
Thermal Resistance
Temperature rise per watt of heat
< 0.05 °C/W
Pressure Drop
Pressure loss of flowing fluid
< 30 kPa at standard flow rate
These two metrics are mutually constrained: denser microchannels lower thermal resistance but drastically increase pressure drop, demanding more powerful pumps.
CNC machining precision directly determines whether these targets are met.
2. Main Structural Types of Liquid Cold Plates
Type 1: Machined‑Channel Cold Plates
The most mainstream CNC solution. Flow channels are milled directly into aluminum or copper plates, then sealed with a cover plate via brazing or diffusion bonding.
Advantages: design flexibility, customization‑friendly, high precision
Typical channel dimensions: width 1–5 mm, depth 1–10 mm
CNC challenge: extremely high sidewall verticality for large depth‑to‑diameter ratios
Type 2: Microchannel Cold Plates
Channel width < 1 mm, down to 0.2–0.5 mm, widely used in high‑end GPU and power module coolers.
Advantages: large heat exchange area, ultra‑low thermal resistance
CNC challenge: requires ultra‑fine tools (0.3–0.5 mm diameter); critical vibration control
Equipment: high‑speed precision machining centers, spindle speed > 20,000 RPM
Type 3: Pin‑Fin Cold Plates
Dense pin arrays (1–3 mm diameter) machined on the base plate; coolant flows around pins to enhance turbulent heat transfer.
Advantage: 20–40% higher heat transfer efficiency than channel types at the same pressure drop
Processes: CNC milling or EDM
Type 4: Braided/Folded Fin Cold Plates
Aluminum foil folded into fins then brazed into flow channels, common for high‑power IGBT modules.
CNC role: mainly machining the frame
Welding challenge: brazing void rate < 5%
3. Material Selection: Aluminum vs. Copper
Aluminum Alloy Cold Plates
6061‑T6: best overall performance, good machinability, low warpage risk
6063‑T5: for extrusion; preferred for complex profiles
1060 pure Al: highest thermal conductivity (> 200 W/m·K), lower strength; ideal for thin‑wall, high‑heat applications
Oxygen‑Free Copper (C10100 / C11000) Cold Plates
Superior thermal conductivity; ideal for direct contact with high‑heat‑flux chips.
Hybrid Structure (Increasingly Popular)
Bottom (CPU/GPU contact): copper insert (max heat transfer)
Main frame: aluminum alloy (weight reduction)
Joining: press fit + thermal grease, or diffusion bonding
4. Core CNC Machining Challenges
Challenge 1: Thin‑Wall Deformation Control
Wall thickness typically 0.8–2 mm; easily deformed by cutting forces.
Trumony Controls:
Vacuum chuck fixtures or low‑melting alloy filling to avoid clamping deformation
Roughing with 0.3 mm stock allowance; natural aging 24 h before finishing
Finishing depth of cut ≤ 0.1 mm; feed rate reduced to 30% of normal
Challenge 2: Deep‑Groove & Microchannel Machining
Deep grooves: high‑pressure through‑tool coolant (> 30 bar) to prevent re‑cutting chips
Microchannels: machined in temperature‑controlled workshop (±1 °C) to eliminate thermal distortion
Challenge 3: Sealing Surface Flatness
Flatness of base and cover sealing surfaces directly affects leak‑proofing.
Trumony capability: flatness 0.005 mm after precision grinding, meeting diffusion bonding requirements.
Challenge 4: Precision Threads & Quick‑Connect Ports
Inlet/outlet ports use NPT/G (BSPP) threads or custom quick connectors with tight precision requirements.
Challenge 5: Internal Cleanliness
No chips allowed inside flow channels (risk of pump damage or microchannel clogging).
Trumony Cleaning Process:
Ultrasonic cleaning (40 kHz, 15 min)
High‑pressure air purging (0.5 MPa, cycling all ports)
Deionized water flushing
Endoscopic inspection
Pressure test (2× working pressure, hold 30 min)
5. Quality Inspection & Validation
Leak Test
Helium mass spectrometer leak detection: < 1×10⁻⁹ Pa·m³/s
Thermal Resistance Test
Heater block + temperature sensors to verify thermal resistance performance.
Flow & Pressure Drop Test
Flow meter + differential pressure sensor to confirm no clogging or deformation in internal channels.
6. Trumony Liquid Cold Plate Machining Capabilities
22 years of precision CNC machining expertise
Full process: CNC milling → cleaning → vacuum brazing / FSW → surface treatment → testing
Microchannel precision, high flatness, zero leakage, high cleanliness
Serving server cooling, industrial electronics, medical device customers in the US, Germany, and globally
7. Applications & Market Trends
Key Applications
AI servers & high‑performance computing (HPC)
Data center liquid cooling systems
EV power electronics & battery thermal management
Industrial power modules & medical equipment
2025–2026 Technology Trends
Direct Liquid Cooling (DLC)
Coolant routed directly to chip backsides; thermal resistance reduced by >50%.
Two‑Phase Cooling
Liquid‑to‑vapor phase change absorbs heat; efficiency 3–5× single‑phase liquid cooling.
Immersion Cooling
Entire server immersed in dielectric fluid; precision machining of internal distribution manifolds remains critical.
8. 5 Key Criteria for Selecting a CNC Cold Plate Supplier
✅ Leak testing capability
Must have airtight test equipment; helium mass spectrometer preferred for high‑end applications.
✅ Microchannel precision
Require channel width verification (SPC data); Cpk ≥ 1.33.
✅ Internal cleanliness control
Complete ultrasonic cleaning + endoscopic inspection with traceable records.
✅ Welding capability
In‑house or stable partner for aluminum brazing / friction stir welding.
✅ Thermal testing capability
Able to provide verified thermal resistance data.
Summary
A liquid cold plate may look like a simple “grooved metal plate,” but it integrates materials science, fluid mechanics, precision manufacturing, and quality control.
With rapid expansion of AI computing infrastructure, liquid cold plates will be one of the fastest‑growing precision component categories over the next five years.
Trumony — 19 years focused on precision CNC machining — provides custom liquid cold plate manufacturing for server cooling, industrial electronics, and medical device clients worldwide.
