High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel

High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel
High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel
High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel

Large Image :  High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel

Product Details:
Place of Origin: China
Brand Name: Trumony
Certification: ISO9001
Model Number: TR-CY009
Payment & Shipping Terms:
Minimum Order Quantity: 500KG
Price: Negotiation
Packaging Details: Export Standard Packing
Delivery Time: 35days including tooling time
Payment Terms: L/C, T/T
Supply Ability: 100000ton/Every Year

High Precision 3003 / 3102 Aluminium Heat Exchanger Tube Microchannel

Description
Type: Heat Sink Aluminium Profile, Glass Wall Aluminium Profile, Transport Aluminium Profile, Industrial Aluminium Profile Shape: Customized
Grade: 1000,3000, Alloy: Alloy
High Light:

3003 Aluminum Extruded Tube

,

Microchannel Aluminium Heat Exchanger Tube

,

3102 Aluminium Heat Exchanger Tube

High Precision 3003 / 3102 Aluminium Heat Exchanger Microchannel Tube Supplier



Mechanical Properties of flat aluminum micro channel tube
No. Alloy Temper Tensile Strength(Mpa) Yield Strength(Mpa) Elogation(%)
1 1050 O/F/H111/H112 ≥ 65 ≥ 20 ≥ 25
2 1100 O/F/H111/H112 ≥ 75 ≥ 20 ≥ 25
3 1197 O/F/H111/H112 ≥ 80 ≥ 25 ≥ 20
4 3102 O/F/H111/H112 ≥ 75 ≥ 20 ≥ 25
5 3R03 O/F/H111/H112 ≥ 80 ≥ 25 ≥ 20



1. Chemical Composition

No. Alloy Si Fe Cu Mn Mg Cr Zn V Ti
1 1050 ≤ 0.25 ≤ 0.40 ≤ 0.05 ≤ 0.05 ≤ 0.05 - ≤ 0.05 ≤ 0.05 ≤ 0.03
2 1100 ≤ 0.95(Fe+Si) 0.05-0.20 ≤ 0.05 - - ≤ 0.10 - -
3 1197 ≤ 0.15 ≤ 0.20 0.40-0.55 0.10-0.20 ≤ 0.03 ≤ 0.05 ≤ 0.05 ≤ 0.05 ≤ 0.05
4 3102 ≤ 0.40 ≤ 0.70 ≤ 0.10 0.05-0.40 - - ≤ 0.30 - ≤ 0.10
5 3R03 ≤ 0.15 ≤ 0.15 ≤ 0.01 0.90-1.10 ≤ 0.03 ≤ 0.03 ≤ 0.05 ≤ 0.05 ≤ 0.05



2. Size Tolerance

Width Thickness Wall Thickness Length Lateral Curvature Frontal Curvature Twsiting Dgree
± 0.05mm ± 0.03mm ± 0.05mm ± 0.03mm ≤ L× 0.2% ≤ L× 0.25% ≤ L× 0.15%



3. Our products will be tested in strict standard before delivery, some data for your reference.


No Products' Testing Name Contents and requests
1 Corrosion Resistance Salt spray test: ≥ 750 hours
2 Zn Coating Standards 6/8/10/13± 2g/square meter
3 Flux Cotaing Standards 10-15± 2g/square meter



4. Commercial terms



Minimum Order Quantity: 100pcs, less quantity can negotiate
Price: negotiation
Payment Terms: T/T or LC
Supply Ability: 1000,000 pcs per year
Delivery Time: 15-30 working days after received your down payment
Packaging Details: Standard export packaging



3003 Extrusion Micro Channel Aluminum Flat Tube is widely used for manufacturing of various kinds of heat exchangers:

Air conditioning
Engine cooling
Condensers
Evaporators
Radiators
Heater cores
Charge air coolers/intercoolers
Engine oil coolers/transmission oil coolers



Our advantage:

1. Since 2006, we have rich experience in this industry in China;
2. Good reputation in aluminum material industry;
3. We have our own development department for new material research;
4. Good experience and cooperation with big client in the world;
5. With Certificate ISO9001-2008;
6. High performance cost ratio;
7. Fast delivery time 15-30 days for flat aluminum micro channel tube;
8. Good communication skills, and good after sells service, and understandings for customers;
