Product Details:
|
| Product Name: | Serpentine Cooling Ribbon | Raw Material: | Aluminum |
|---|---|---|---|
| Alloy & Temper: | 3003, 6061, H112 | Surface Treatment: | Powder Spray, Insulation Coating |
| Application: | Electric Vehicle, Household ESS, Commercial ESS | Design Service: | Support |
| Thermal Simulation: | Available | Package: | Exported Standard Wooden Package |
| Battery Type: | Cylindrical Cell (18650,21700, 3270, 4680, 4695), Prismatic Cells, Pouches | Key Words: | Water Cooled Plate, Snake Tube For 21700 |
| High Light: | Serpentine Cooling Ribbon,Lithium Ion Battery Serpentine Ribbon,Snake Tube For Commercial Vehicle |
||
High Performance Lithium ion Battery Cooling Snake Tube for Commercial Vehicle
Water cooling system is becoming more and more popular thanks to its high thermal performance and compact structure. Compared with traditional air cooling, the liquid cooling system is better heat dissipation, and land area saving.
Battery thermal management is very critical in an operation of EV. Trumony is an expert of providing all kinds of heat exchangers: we can do customized shape, to make the parts fit into different packs. For example: stamping type cooling plate for prismatic cells / battery pack, extrusion snake tube for cylindrical cells, such as 21700, 18650, 3270, 4680 big cell, roll bonded cooling plate.
| Product name | Serpentine cooling ribbon for Electric Vehicle |
| Tube size | According to your boundary size 55*3mm for 21700 / 65*3.5mm for 4680 |
| Type of cells | 18650, 21700, 32700, 4680 battery cells |
| Structures | Extrusion aluminum tube + Inlet & outlet+quick connector |
|
Length |
It depends on your module |
| Surface treatment | Insulation coating / Powder spary |
| Related products | Quick connector, thermal interface material (silicon pad), pump, etc. |
| Services | Cooling tube design, thermal simulation, flow path design, finalize production feasibility |
According to various applications and requirements of thermal management, we can provide a range of battery cooling solutions.
1) Stamped type cooling plate for prismatic cells / battery pack.
2) Extrusion snake tube for cylindrical cells, such as 21700, 18650, 3270, 4680 big cell.
3) Extruded tube with manifold for soft battery pack.
4) Roll bond cooling plate for heating / cooling.
Our Advantages:
1) Flexible design solutions for all kinds of battery pack.
(According to your module provide customized cooling plate)
2) Design service, we have R&D department, can do design finalization, flow and heat simulation.
3) CNC centre to make customized inlet/outlet connector.
4) Thermal Interface Material, such as thermal silicone pad, Insulation coating etc.
Keyword:
water cold ribbon, liquid cooling plate, snake tube for EV, harmonica tube radiator, 21700 battery cooling tube, EV manufacturer, Lithium ion Battery Cooling, Aluminum cooling tube, water cold plate, Cooling pipe, snake tube for 4680 cells.
Chemical composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | V | Ti |
| 1050 | ≤0.25 | ≤0.40 | ≤0.05 | ≤0.05 | ≤0.05 | --- | ≤0.05 | ≤0.05 | ≤0.03 |
| 1100 | ≤0.95(Si+Fe) | 0.05~0.20 | ≤0.05 | -- | -- | ≤0.10 | --- | --- | |
| 3102 | ≤0.40 | ≤0.70 | ≤0.1 | 0.05~0.4 | --- | --- | ≤0.3 | --- | ≤0.10 |
It can be customized according to customers' request!
Mechanical Properties
| Alloy | Temper | Tensile Strength | Yeild Strength | Elongation |
| 1050 | O/F/H111/H112 | ≥65MPa | ≥200MPa | ≥25% |
| 1100 | O/F/H111/H112 | ≥75MPa | ≥200MPa | ≥25% |
| 3102 | O/F/H111/H112 | ≥75MPa | ≥200MPa | ≥25% |
| 3003 | O/F/H111/H112 | ≥75MPa | ≥200MPa | ≥25% |
Q: How long does it take for samples and mass production?
A: Usually it will take 15-20 days for new moulds and free samples (within 5kg), after confirmation, 25-30 days for mass production.
Q: OEM/ODM available?
A: Yes,we can!
Q: Can you assist in design?
A: Yes, we can! We have a strong and experienced design team.
Q: Could you provide sample?
A: Yes, We are honored to offer you samples for quality check.
Q: Is sample order accepted?
A: Yes,we accept sample order and we can provide design service!
