Product Details:
|
| Name: | Silicone Grease | Thermal Conductivity: | 1-6W/m*K |
|---|---|---|---|
| Application: | CPU | Hardness: | 5~80Shore 00 |
| Density: | 2.5-3.5g/cc | Voltage Resistance: | 6-10 KV/mm |
| Viscosity: | 10^12 Ω*cm | Flame Rating: | V0 UL-94 |
| Color: | Gray/Customize | Feature: | Insulation |
| High Light: | Silicone Thermal Grease,Insulation Heat Conductive Silicone Grease,Electron Component Silicone Grease |
||
Insulation Heat Conduction Silicon Grease For Electron Component
Thermal Interface Materials (TIM), is one of the common ways of heat dissipation, heat dissipation is an enduring topic, we are familiar with the normal operation of mobile phones, tablets and computers can not be separated from the role of various types of thermal conductivity of thermal conductivity of the material, especially at the moment with the development of high-performance, thin and lightweight smart devices, the requirements of thermal conductivity of the material continues to improve!
Silicone grease is divided into two kinds of thermally conductive silicone grease and lubricating silicone grease, with good waterproof sealing, waterproof, solvent resistance and anti-creepage performance, does not corrode the metal, and rubber has a better adaptability, used for sanitary equipment. Seal ring, waterproof sealing and lubrication of electrical and electronic industry. Silicone grease is refined synthetic oil as a base oil, and add structure stabiliser, anti-corrosion additives refined from the
| silicone grease | |||||
| Performance test | test method | 30108-0120 | 30108-0270 | 30108-0400 | 30108-0350 |
| Color | visual | white | white | white | white |
| Conductivity(W/m*K) | ISO 22007-2 | 1.2 | 2.7 | 4.0 | 3.5 |
| Thermal resistanse(oC-cm2/W) |
ASTM D5470 80oC@50psi |
0.2 | 0.18 | 0.12 | 0.05 |
| Density(g/cc) | ASTM D792 | 2.5 | 3.0 | 3.2 | 3.3 |
| viscosity(mPa*s) | ASTM D2196 | 50,000 | 20,000 | 70,000 | 100,000 |
1, has good heat transfer, at the same time has a non-dry solid, not solidified, not melted, odourless and non-toxic;.
2,Excellent thermal conductivity, with low oil separation, high temperature does not separate oil, high temperature does not flow.
3, excellent insulating properties, non-toxic, odourless, non-curing, non-corrosive to the substrate, stable chemical and physical properties.
4, high and low temperature resistance, water, ozone, climate aging, can be used for a long time in high and low temperature environment.
A)How could I get a sample?
Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order.
B)Sample time?
Within 10-30 days.
C) Whether you could make our brand on silicone grease ?
Yes. We can print your Logo on both the silicone grease and the packages if you can meet our MOQ.
D) Whether you could make silicone grease by our color?
Yes, The color of silicone grease can be customized if you can meet our MOQ.
E) How to guarantee the quality of silicone grease ?
1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
F) : Do you accept R & D assignments?
Yes, as long as we can do products, we can according to Your Design Requirements of individual R & D.
