Heat Transfer Heavy Wall Aluminum Tubing 0.45 - 0.8mm Thick Corrosion Resistance
  • Name
  • Name

Heat Transfer Heavy Wall Aluminum Tubing 0.45 - 0.8mm Thick Corrosion Resistance

MOQ: 3-5ton
Price: negotiable
Standard Packaging: plywood case
Delivery Period: 15-20days
Supply Capacity: 20000mts
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Trumony
Certification
ISO 9001:2000,ISO/TS16949:2002
Model Number
TR-012
Material:
3000 Series
Thickness:
0.45-0.8mm
O.D.:
6.35-9.52mm
Function:
Increase Heat Transfer Rate,decrease Material Cost
Application:
Evaporator, Condenser, Connection Tube
Highlight:

aluminium alloy tube

,

round aluminum tubing

Product Description

3003 / 3103 Aluminum Inner Grooved Tube For Evaporator / Condenser / Connection Tube





Product Description:

Aluminum Inner Grooved Tube is made of 3003/3103 al-alloy materials through extrusion and drawing that determine its better ductility.And the tooth height from 0.05mm to 0.25mm contributes to its heat conduction performance which is necessary in air-conditioners' heat exchange system.It must be a wise choice for air conditioner factories because of its lowest cost.



Our advantage:

By employing the lasted fine finish and years of experience,we produces high quality,high precision extruded aluminum round tube.



Parameter for aluminum Inner Groove Tube

Specification bottom wall thickness Tooth height Tooth number Helix Angle Rib-top Angle g/m
φ7mm 0.4-0.5 0.05-0.18 40-50 18° 50° 28+/-3
φ9.52mm 0.45-0.55 0.05-0.18 45-55 18° 50° 45+/-3
φ7.94mm 0.4-0.5 0.05-0.18 40-50 18° 50° 40+/-3



The parameters in above form can also be adjusted as per customer's request.
Tensile:120MPa min
Elongation:35% min
Expanding:40% min
Density:2.7



Application field:
Air condition,refrigeration and cooling system

Automotive air condition:
Solar application



Product feature:
1. Light-weight
2. Good thermal conductivity properties and electrical conductivity
3. Good corrosion resistance
4. Good forming and bending properties
5. High recycling value
6. Small deviation range
7. High surface quality



Heat Transfer Heavy Wall Aluminum Tubing 0.45 - 0.8mm Thick Corrosion Resistance 0
