Product Details:
|
| Synonym: | Aviation Aluminum Coil | Alloy: | 7020/7N01/7075/7050 |
|---|---|---|---|
| Temper: | O/T4/T6 | Application: | Aircraft/Aerospace/Railway Transportation/Automotive /Marine |
| Certificate: | Aviation/NADCAP Certified | Thickness: | 0.2-3.5mm |
| Width: | 1200-2650mm | Coil ID: | 505/605mm |
| Coil OD: | 2560mm | Packing: | Fumigated Pallet Specialized For Export |
| High Light: | 7050 Aluminum Coil,7075 Aluminum Coil,7N01 Aluminium Coil |
||
7xxx Anti-Corrosion Aviation Aluminum Coil
With the unique advantages of low density, moderate strength, easy processing and forming, strong corrosion resistance, abundant resources and strong recyclability, the development of aviation industry has formed an inexplicable relationship with the application of aluminum alloy materials.
Specification of Cold rolled aluminum coil:
| Alloy series | Typical alloy | Typical temper | Specification | |||
| Thickness | Width | ID | OD | |||
|
1xxx 3xxx 5xxx |
1050,1100,3003,3004,5052,5083,5182,5754 |
O,H12/22/32 H14/24/34 H16/26/36 H18/28/38 |
0.20-3.5mm | 1200-2650mm | 505/605mm | 2560mm |
|
2xxx 6xxx 7xxx |
2024,6016,6061,6082,7020,7N01,7075,7050 | O,T4,T6 | 0.30-3.5mm | 1200-2650mm | 505/605mm | 2560mm |
Other sizes are available according to customer's request.Besides aluminum coil,we are also supplying the aluminum alloy plate as per customers' requirement.
Applications:
The 7xxx series aluminum coil we are supplying are including 7050,7075,7N01,7021 etc,the application for each alloy is as follows:
7050alloy: Radar structural parts ,manufacturing structure of aircraft, other high stress structural elements which demand high strength and strong corrosion resistance etc.
7075alloy: Aviation, aerospace, moulding, mechnical equipment, tooling and fixture etc.
7N01alloy: Bed plate of high speed train and coal transportation vehicle etc.
7021alloy: Unit load device of aviation,components for aerospace and aviation
| ALLOY NO. | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
| 7075 | 0.4 | 0.5 | 1.0-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-6.1 | 0.2 | Rem |
| 7050 | 0.12 | 0.15 | 2.0-2.6 | 0.1 | 1.9-2.6 | 0.04 | 5.7-6.7 | 0.06 | Rem |
Terms and conditions:
Trade term:CIF / CFR / FOB
Payment term:30% before production+70% before shipment;or 100% Irrevocable L/C at sight;Or we can further cummunicate with each other about this part.
Shipment:Normally it is about 30-35days
MOQ:5 metric tons for each thickness. (Normally it is formed according to the concrete specifications.)
Quantity tolerance:+/-10% of total quantity as confirmed PI.
