Alloy 3003/4045 Aluminium Coil For Radiator Side Sheet Decoration EDT Surface
| Product name: | Aluminum Coil | Material: | Aluminum |
| Alloy or not: | Alloy | Alloy States: | 5000 / 6000 Series Etc |
| Temper: | T4P / O / H111 Etc | Certification: | CE, ISO |
| High Light: | Alloy 3003 Aluminum Coil,EDT Surface Aluminum Coil,Radiator Side Sheet Decoration Aluminum Coil |
||
Alloy 3003/ 4045 Aluminium Strips Coils for Radiator Side Sheet Decoration
Other than surface decoration, most building projects rely on aluminum coil to help design structures, doors, windows, ceilings, curtain wall profiles, pressure plates, color coating sheets, etc
Application:
Body cover and inner panel, including four doors, two covers and wing panels, etc.
Advantages:
Typical mechanical properties:90°
The outer plate of the car body
1. good punching molding
2. good flanging performance.
3. good Roping line
4. with EDT surface, uniform roughness. Main alloy states are 6014 and 6016.
The interior plate of the car body
1. good impact molding performance,
2. YPE < 0.6%, mainly 5182 and 5754 alloy states, inner plate 6016, 6014 etc.
Good Flanging Performance
Good Surface
Mechanical property
| T4 | ||||||
| Alloy states | Rm | Rp0.2 | A50mm% | Ag% | R10% | N4%-6% |
| 6014-IH | 200 | 90 | 25 | 22 | 0.70 | 0.30 |
| 6016-IH | 210 | 92 | 26 | 25 | 0.6 | 0.30 |
Product Specification
| Alloy States/Temper | Character | Thickness | Width | Surface |
| 5754/O | ST | 0.5-4.0mm | 1000-2200mm | As requested |
| 5182/O | RSS | |||
| 5052/H32 | RSS | |||
| 6016/T4 | IH | |||
| 6014/T4 | IH | |||
| 6016/T4 | IBR | |||
| 6051/T4 | HS | |||
| 6111/T4 | HS |
Terms and conditions:
Trade term:CIF / CFR / FOB
Payment term:30% before production+70% before shipment;or 100% Irrevocable L/C at sight;Or we can further cummunicate with each other about this part.
MOQ: Negotiable
Quantity tolerance:+/-10% of total quantity as confirmed PI.
