Product Details:
|
| Aluminum Alloy: | Alloy 8011, Alloy1100, Alloy8006 | Temper: | HO/H24 |
|---|---|---|---|
| Thickness: | 0.1~0.15mm Or Customized | Cladding Rate: | 4~30% |
| Width: | 100~200mm For Household HVAC, ＞300mm For Industry HVAC | Customized: | YES |
| Surface Treatment: | Bare/ Hydrophilic / Epoxy | Pacakage: | Woden Packing |
| Applications: | Air Conditioner, Aluminum Conderser, Radiator, Air Cooled Heat Exchangers | Keywords: | Fin Stock, Aluminum Foil, HVAC |
| High Light: | 8006 Aluminum Cladding Foil,Brazed Aluminum Cladding Foil,Heat Exchangers Aluminum Cladding Foil |
||
8006/8011 Brazed Aluminum Cladding Foil for Heat Exchangers Condenser
Aluminum foil is a special material for the manufacture of heat exchanger fins for air conditioners. The air-conditioning foil used in the early days was plain foil. In order to improve the surface properties of plain foil, anti-corrosion inorganic coating and hydrophilic organic coating are applied before forming to form hydrophilic foil.
Specification:
1) Alloy 8011 1145, 1235
2) Thickness: 0.008-0.2mm
3) Width Size: 200mm-1250mm
4) Customer's specification is welcomed
5) Coating: Bare aluminum foil, hydrophilic aluminum foil, epoxy aluminum foil.
Characteristic:
Tensile strength(MIN): 50 Mpa
Breaking elongation(MIN): 15%
Bond strength(MIN): 4 N/cm
Appearance: Blue or natural color, Very smooth, Non-knife-cut mark.
Usage: Used for waterproof layer and shield layer.
| Aluminium coil/Aluminium Strip | |||
| Aluminium Alloy | Thickness (mm) | Width (mm) | Temper |
| A8011 | 0.2-500 | 20-2500 | O,H12,H14,H16,H18,H22,H24,H26 |
| Material process | both CC AND DC | ||
| Customerize size | Size can be produced as per clients requirement | ||
| Surface | Mill finish ,Color coated(PVDF& PE),Stucco Embossed ,Bright Polish ,Anodizing | ||
| Mirror, Brush, Perforated, Tread plate,Corrugated etc | |||
| Quality Standard | ASTM B209,EN573-1 | ||
| MOQ per size | 2 tons | ||
| Payment Terms | TT OR LC OR DP at sight | ||
| Delivery time | Within 25 days after receipt the lc or deposit | ||
| Material Quality | tension levelled,Free of defects like oil stain,Roll Marks,Waves,Dents, Scratch etc , | ||
| A+++ quality | |||
| Application | Construction ,Building, ACP, Decoration, Roofing, Mould, Ship Building, Lighting, | ||
| Aircraft, Oil Tank ,Truck Body, car body, TFT | |||
| Packing | Standard export worthy wooden pallets, and standard packing is about 2.5 tons/pallet | ||
| coil ID:508MM | |||
| coil weight also can be as per client's requirement from 50kgs to 8000 kgs per coil | |||
Packing:
1) Plastic drum.
2) According to the customer's demand.
FAQ:
Q: Are you a trading company or manufacturer?
A: Yes,we are a factory with more than 10 years history in this industry.
Q: What is your terms of payment ?
A: Normally 30% TT in advance, balance paid before shipment.
Q: How long does it take for samples and mass production?
A: Usually it will take 15-20 days for new molds and free samples (within 5 kg),;after confirmation, 25-30 days for mass production.
Q: OEM/ODM available?
A: Yes,we can!
Q: Could you provide sample?
A: Yes, We are honored to offer you samples for quality check.
Q: Is sample order accepted?
A: Yes,we accept sample order and we can provide design service!
Contact Person: Mr. Tracy
Tel: +8613584862808
Fax: 86-512-62538616
