Customized High Quality Battery Vechical Electric High Thermal Conductivity Heat Conductive Silicone Pad
| Quality: | High Quality | Color: | Customized |
| Application: | 5G/Server/New Energy Vehicle/3C/LCD TV/home Energy Storage | Price: | Beat Price |
| Material: | Glass Fiber Cloth, Silicone | Thermal conductivity: | 1.5W/m*k---12W/m*k |
| Thickness: | 0.4mm---10mm | Hardness range: | Shore 00 5~80 |
| High Light: | Battery Aluminum Cooling Plate,Thermal Heat Conductive Silicone Pad,Vehicle Heat Conductive Silicone Pad |
||
Product Description:
| Thermal Pads Series | ||||||
| Item No. |
Thermal Conductivity (W/m*K)
|
Hardness (Shore 00) |
Density (g/cc) |
Voltage Resistance (KV/mm) |
Volume Resistivity (Ω*cm) |
Flame Rating (UL-94) |
| 301-0150 | 1.5 | 5~80 | 1.8 | 10 | 10^12 | V0 |
| 301-0200 | 2 | 5~80 | 2 | 10 | 10^12 | V0 |
| 301-0300 | 3 | 15~80 | 3.0 | 8 | 10^12 | V0 |
| 301-0400 | 4 | 15~80 | 3.3 | 8 | 10^12 | V0 |
| 301-0600 | 6 | 20~80 | 3.5 | 8 | 10^12 | V0 |
| 301-0800 | 8 | 30~80 | 3.6 | 8 | 10^12 | V0 |
| 301-1000 | 10 | 30~80 | 3.3 | 6 | 10^12 | V0 |
| 301-1200 | 12 | 30~80 | 3.210 | 6 | 10^12 | V0 |
Company Introduction:
FAQ:
A) How could I get a sample?
Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order.
B) Sample time?
Within 30 days.
C) Whether you could make our brand on your products?
Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
D) Whether you could make your products by our color?
Yes, The color of products can be customized if you can meet our MOQ.
E) How to guarantee the quality of your products?
1) Strict detection during production.
2) Strict sampling inspection on products before shipment and intact product packaging ensured.
F) Do you accept R & D assignments?
Yes, as long as we can do products, we can according to Your Design Requirements of individual R & D.
Thermal Interface Materia Thermal Silicone Pad For Lithium Battery Pack
Thermal Interface Materia Thermal silicone pad For Lithium Battery Pack Discription of Thermal silicone pad: Thermal silicone pad has a certain degree of flexibility, excellent insulation, compressibility, natural viscosity of the surface, specially for the use of gap heat transfer design scheme ...
High Performance One Component Thermal Gap Filler for PCB CPU
High Performance One Component Thermal Gap Filler for PCB CPU Discription of Thermal Gap Filler: Thermal Gap Filler is a gel-like thermally conductive filler material made of silica gel compounded with thermally conductive filler, stirred, mixed and encapsulated. It adopts dispensing design, when ...
Insulation Heat Conductive Silicone Grease For Electron Component
Insulation Heat Conduction Silicon Grease For Electron Component Discription of Silicone Grease : Thermal Interface Materials (TIM), is one of the common ways of heat dissipation, heat dissipation is an enduring topic, we are familiar with the normal operation of mobile phones, tablets and ...
3W / M * K Thermal Gap Pads Conductive Pad For Lithium Battery Electric Vehicle
3W / M * K Thermal Gap Pads Conductive Pad for Lithium Battery Electric Vehicle Discription of thermal conductive pad : The thermal conductive pad is generally located between the liquid cooling plate and the cell pole, which can effectively exclude air and achieve good filling and thermal ...
