Industrial Aluminium Packaging Foil , Laminated Soft Foil Packaging For Food

MOQ:	5 metric tons
Price:	negotiation
Standard Packaging:	Standard export packaging
Delivery Period:	40 working days after received your down payment
Payment Method:	T/T or LC
Supply Capacity:	40,000 mt per year

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Trumony

Certification

ISO9001-2008

Model Number

TR-F010,TR-F131,TR-F141

Alloy:

1235, 8079, 8011 And Etc.

Temper:

HO And Etc.

Thickness:

0.005 - 0.2 Mm

Width:

200 - 1850 Mm

I. D:

76 Mm, 152 Mm

Normal O. D:

400 - 600 Mm

Pin Hole:

According To GB/T3198-2010

Other Sizes And Specifications:

Available According To Customer's Request.

Highlight:

packaging aluminium foil

aluminum foil sheets

Product Description

Industrial Aluminium Packaging Foil , Laminated Soft Foil Packaging For Food

1. Description of our production

Our chemical composition:

Alloy	Si	Fe	Cu	Mn	Mg	Zn	Cr	Ti	code
8011	0.5-0.9	0.6-1.0	0.1	0.2	0.05	0.1	0.05	0.08	1
1235	Si+Fe:0.65		0.05	0.05	0.05	－	－	0.06	2
8079	0.05-0.3	0.7-1.3	0.05	－	－	0.1		－	3

Our mechanical property:

Foil Classification	Thickness(mm)	Alloy	Thickness Tolerrance	Width Tolerance

Thin Gauge 0.005-0.009	0.005	1235 8011 8079	±5%	(200-1880)±1
	0.006
	0.0065
	0.007
	0.008
	0.009
Mechanical Performance	Strengthen(Mpa)	50-160 (according to customer's requirements and technical agreement)

	Elongation(%)	0.5%-8% (according to customer's requirements and technical agreement)

Typical core I.D.		Φ76.2 Φ152

Typical Coil O.D.		Φ300 Φ500 Φ1000 (selectable)

Trace Elements		pb≤0.01 cd≤0.01 As≤0.01

Wettability		≥Class B

Pin no. (P/m²)		according to custiomer's requirements and technical agreement

Light (L)		according to custiomer's requirements and technical agreement

Coil Connector		according to custiomer's requirements and technical agreement

Surface Quality		1 even serface flatness 2 clean surface without corrosion,spots,wrinkles,scratches,light and dark lines,marks slots etc. 3 no light spots,marke,wheel mark and black line. 4 no yellow spots from the lubricatio oil burning and breaks on the surface of the final production.


Quality Outside		No defects such as burring, cracks, telescoping, loosen coils, core out, arrow etc.. Welding firmly, foil section neat and clean.

2. Our advantage

1. Since 2004, we have rich experience in this industry in China;

2. Good reputation in laminated soft packaging areas;

3. We start our productions from aluminum ingot,so we can control the quality as well;

4. We have our own development department for new material research;

5. Good experience and cooperation with big client in the world;

6. With Certificate ISO9001-2008;

7. High performance cost ratio;

8. Fast delivery time;

9. Good communication skills, and good service and understandings for customers;.
