H22 / H24 Aluminum Heat Transfer Foil For Home Air Conditioner Thickness 0.2 mm

Basic Properties
Place of Origin: China
Brand Name: Trumony
Certification: TS16949-2008
Model Number: TR-1100
Trading Properties
Minimum Order Quantity: 5 Tons
Price: Negociable
Payment Terms: L/C, T/T
Supply Ability: 800,000 Per Year
Tags

aluminum foil roll

aluminium foil packaging

heavy duty aluminum foil
Specifications
Alloy: 1100 Feature: Unclad
Thickness: 0.08mm - 0.2 Mm Cladding Rate: 8%
Shape: Roll
High Light:

aluminium foil rolls

,

thermal transfer foil
Product Description



Alloy 1100 , Thickness 0.2 mm Aluminum Heat Transfer Foil Manufacture For Condenser



Quick Details :



1 . Alloy :1100 ,1200 , 3102 , 8011

2 . Temper : O , H22 , H24 , H26

3 . Thickness : 0.08 - 0.2 mm

4 . Width : 60 - 1440 mm

5 . Inside Diameter : 75 , 150 , 200 , 300 , 400

6 . Outside Diameter : 400 - 1400 mm



H22 / H24 Aluminum Heat Transfer Foil For Home Air Conditioner Thickness 0.2 mm 0





Chemical Composition ( For Reference Only )





NO



  Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Others Al



1



 1100 0.33 0.27 0.05-0.20 0.05 - - - - - 0.15 99.0





Mechanical Performance ( For Reference Only )





Temper





Tensile Strength

Rm(MPa)

 Yield Strength Rp0.2(Mpa)

Erichsen

(mm)



O

80- 110

20

6.0


H22

100 - 135

16

5.5


H24
 		 115 -145 12 5.0

H26

125 - 160
 		 8 4.0

H18
 		 160 1 -






Our Advantages :



1 . we have extensive experience in providing different presentations and uses aluminum exporting to Mexico, Germany, France, Italy, Korea, Turkey, Iran and India .It has been proven that we have reliable quality and competitive price, customers in these different countries.



2 . We start our productions from aluminum ingot,so we can control the quality as well;



3 . High performance cost rate;
