Product Details:
|
| Alloy: | 3003 | Feature: | Unclad |
|---|---|---|---|
| Thickness: | 0.08mm - 0.2 Mm | Shape: | Roll , Coil |
| Highlight: | industrial aluminium foil,thermal transfer foil |
||
Size 0.08mm * 16mm With Alloy 3003 Aluminium Heat Exchanger Fin Foil For Radiator Of Car
Details of aluminium Heat Exchanger Fin Foil :
1 , Core Alloy: 1060, 3003, etc
2 , Thickness: 0.2-3.0mm
3 , Width: 12 - 1250mm (max)
4 , Temper: HO, H14 etc
5 , I. D.: 150mm, 200mm, 300mm, 400mm, 500mm
6 , Normal O. D.: 900-1450mmm
7 , Other sizes is available according to customer's request
Chemical Coposition ( For Reference Only )
Chemical composition of core material,cladding material about aluminum alloy and composite-material for welding heat exchanger
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Zr | Ti | code |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | － | 0.1 | 0.05 | 0.03 | 1 |
Remarks : we also could produce according to customer request.
| Temper | Tensile Strength | Yield Strength | Elongation |
| O | 95-135 | > / = 35 | > / = 10 |
| H14 | 140-185 | > / = 125 | > / = 1.0 |
| H16 | 185-225 | > / = 160 | > / = 0.5 |
| H18 | > / = 190 | > / = 170 | > / = 0.5 |
Application
Our product could be used in a variety of heat exchanger constructions which the basic capacibility is to efficiently transfer heat. Also this fin foil can be used for evaporator and condenser in most residential, automotive ,and commercial air conditioning units and in humidifiers and etc.
Experienced R&D team
We have our own R&D center which provides our related departments with newest & updated technique. We are also willing to offer our clients help to meet the change of HVAC and engine cooling industry . just trust us.
Our Traget
We are dedicated to offer heat transfer market with world-class quality products and technical support for all manufacturers of heating exchanger and heater in all over the word.
