Cable Wrapping Shielding PET Coated Insulated Copper Foil High Malleability

Products

Aluminum Air Battery

sales4@trumony.com

+86 18018119117

Contact Now

Cable Wrapping Shielding PET Coated Insulated Copper Foil High Malleability

MOQ:	1ton
Price:	Negotiation
Standard Packaging:	Standard export packaing
Delivery Period:	10 days after down payment
Payment Method:	L/C or T/T
Supply Capacity:	3000 tons yearly

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Trumony

Certification

Model Number

TR-CF080

Copper Thickness:

0.020mm

Width:

100mm

Tensile Strength:

140.8-169.9N/mm2

Elongation(%):

8.94-12.25

Hardness:

Other Requirements:

According To Customers' Requests

Highlight:

packaging aluminium foil

aluminum foil sheets

PET Coated Cable aluminum foil

Product Description

0.020mmCu x 100mm T2 High Malleability PET Coated Copper Foil Cu/PET For Cable Wrapping

1. Copper technical data

Thickness	Density	Hardness	Conductivity	Elongation	Tensile Strength
mm	g/cm3	HV	%IACS	10(%)	Mpa
0.018	8.9	63.12	>=90	26	160

2.Chemical compositions

Cu+Ag	Fe	Bi	Sb	As	Sn	Ni	Zn	O	Pb	S
>=99.99	=<0.005	=<0.001	=<0.002	=<0.002	=<0.002	=<0.005	=<0.005	=<0.06	=<0.005	=<0.005
Remarks: O=<0.06, Impurlty: =<0.1

3. Product Status

M(soft)	Y2(1/2Y)	Y(hard)	T(extra hard)
Product Standard		Refer: GB/T2059-2008. GB/T5231-2001

4. Our advantage

1. Since 1988, we have rich experience in this industry in China;

2. Good reputation in copper cable industry;

3. We have our own development department for new material research;

4. Good experience and cooperation with big client in the world;

5. With Certificate ISO9001-2008;

6. High performance cost ratio;

7. Fast delivery time;

8. Good communication skills, and good service and understandings for customers;.

5. Application

Radio-shielding application of cables, wrapping and shielding application of cable. Cable foil is used as a skin for heat-insulating and electromagnetic shielding to provide high performance for Cable industry

Copper foil is mainly used for shielding of electronic products, especially as transformer, cable, mobile phone, computer, mechanical treatment, aerospace, war industry. These products have the perfect performance of moisture resistance, thermal conductivity and UV-resistance, which make them available to stay away from static electricity and to restrain disturbance of electromagnetic wave. The maximum width is 1380mm.we could also provide shielded ED Copper Foil with all kinds of specification in thickness of 8um-50um

6. FAQ:

1, Q: Are you manufacturer?

A: Yes, we are established in 2003. As a manufacturer our customers are welcome to visit our factory.

2, Q: Do you accept customized orders?

A: Yes, we do. Your customized orders are always welcomed. Please kindly offer us your technical perfrmances or samples so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.

3. Q: How can I get one quotation faster?

A: Pls offer details about your demands as more as possible,insulation thickness,over diameter,nominal voltage,working temperature,color,quantity,application,etc.

4, Q: What's your MOQ?

A: Normally 1 metric tons are requested as the minimum order quantity on our side.

5, Q: What's your payment term?

A: 30% deposit in advance via T/T,balance before shipment.

Cable Wrapping Shielding PET Coated Insulated Copper Foil High Malleability 0
