Alloy 4004 / 3003 / 4004 Aluminum Heat Transfer Plates For Cooling System

Basic Properties
Place of Origin: China
Brand Name: Trumony
Certification: ISO9001-2008
Model Number: TR- 4004/3003/4004
Trading Properties
Minimum Order Quantity: 5 Tons
Price: Negociable
Payment Terms: L/C, T/T
Supply Ability: 800,000 per a year
Tags

aluminum foil roll

aluminium foil packaging

heavy duty aluminum foil
Specifications
Alloy: 4004/3003/4004 Clad Layer: 4004
Type: Brazing Application: Radiator , Condenser , Cooling System
Size: 1.5mm * 1020mm , As Customer Request Temper: HO ，H14
Cladding Ratio: 4 - 8% For Each Side
High Light:

aluminum sheet coil

,

aluminium foil strip

,

4004 Aluminum Heat Transfer Plates
Product Description

Alloy 4004/3003/4004 Temper HO Aluminum Heat Transfer Plates For Cooling System







Alloy 4004 / 3003 / 4004 Aluminum Heat Transfer Plates For Cooling System 0



Core Material

Alloy Si Fe Cu Mn Mg Zn Zr Ti code
3003 0.6 0.7 0.05-0.20 1.0-1.5 － 0.1 0.05 0.03 1



Cladding Material

Alloy Si Fe Cu Mn Mg Zn Zr Ti code
4004 9.0 - 11.0 0.8 0.30 0.05 1.0 - 2.0 0.20 － 0.20 1



Produce capability

  Width(mm) Thickness(mm) Length(mm) Inside Diameters(mm)
Sheet 500-1070 0.5-5.0 500-2500 As customer request



Our advantage



1. Since 1988, we have rich experience in this industry area in China;



2. Great reputation in Aluminum and Copper Areas;



3. We start our productions from aluminum ingot,so we can control the quality as well;



4. We have our own development department for new material research;
