Heat Exchanger Aluminum Heat Transfer Plates Brazing Polished Aluminium Sheet

Products

Aluminum Air Battery

sales4@trumony.com

+86 18018119117

Contact Now

Heat Exchanger Aluminum Heat Transfer Plates Brazing Polished Aluminium Sheet

MOQ:	5 Tons
Price:	Negociable
Standard Packaging:	Standard Export Packaging
Delivery Period:	30 working days
Payment Method:	L/C, T/T
Supply Capacity:	800,000 per a year

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Trumony

Certification

ISO9001-2008

Model Number

TR-4343 / 3003+0.5%

Alloy:

4343 / 3003+0.5%

Clad Layer:

Type:

Brazing

Application:

Intercooler

Size:

1.5 - 3.0 Mm

Temper:

Cladding Ratio:

4 - 8% For Each Side

Highlight:

aluminum sheet coil

aluminium foil strip

Product Description

Alloy 4343 / 3003+0.5% Cu Aluminium Heat Exchager Sheets With High Strength Side Plate For Intercooler

Core Material

Alloy	Si	Fe	Cu	Mn	Mg	Zn	Zr	Ti	code
3003	0.6	0.7	0.05-0.20	1.0-1.5	－	0.1	0.05	0.03	1

Cladding Material

Alloy	Si	Fe	Cu	Mn	Mg	Zn	Zr	Ti	code
4343	6.8 - 8.2	0.8	0.25	0.1	-	0.20	－	0.05	1

Produce capability

	Width(mm)	Thickness(mm)	Length(mm)	Inside Diameters(mm)
Sheet	500-1070	0.5-5.0	500-2500	As customer request

Strength Of Plates Materials

Pre-Braze Strenght ( Mpa)

Post - Braze Strength ( Mpa )

Alloy

Temper

Yield Strength

Tensile Strength

Temsile Strength

Yield Strength

4343/3003+0.5%Cu

> / = 45

120 -150

140

Our Advantage

1 . Over 10 years experience on the energy field, we also can provided technical service such as technical consultation, equipment update, capacity expansion scheme, maintenance and cleaning of the equipment.

2 . ISO9001:2008 international quality standard certification.

3 . One year lifetime guarantee.

4 . High quality and competitive price , fast delivery.

5 . We are not only concerned for the quality of our products and services. Another of our objectives is our respect and care for the environment.

6 . Fast Handling of Inquiries and Orders.
