Auto Air Conditioning Hard Tempered Aluminium Foil Alloy 1100 H18 100 - 135 MPa
  • Name
  • Name

Auto Air Conditioning Hard Tempered Aluminium Foil Alloy 1100 H18 100 - 135 MPa

MOQ: 5 metric tons
Price: negotiation
Standard Packaging: Standard export packaging
Delivery Period: 30 working days after received your down payment
Payment Method: T/T or LC
Supply Capacity: 50,000 mt per year
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Trumony
Certification
ISO9001-2008
Model Number
TR-FS005
Alloy:
1100
Temper:
H18
Thickness:
0.08mm
Width:
313mm
I.D.:
75mm
O.D.:
750-850mm
Rm(MPa):
100-135
A50(%):
16 Min
Cup Drawing Value(mm):
5.5 Min
Other Requirements:
According To Customers' Requests
Highlight:

aluminum foil roll

,

heavy duty aluminum foil

Product Description

0.08 x 313mm 1100 H18 Aluminium Air Cooling Fin Stock for Auto Air Conditioning





1. Description of our production



Our chemical composition:





Alloy

 Si Fe Cu Mn Mg Zn Cr Ti code
8011 0.5-0.9 0.6-1.0 0.1 0.2 0.05 0.1 0.05 0.08 1
1100 0.95 0.05-0.2 0.05 － -- － － 2
1200 1.00 0.05 0.05 － － － 0.05 3



Our mechanical property:



Temper

Tensile Strength

Rm(MPa)

 Erichsen(mm) Elongation(%)
O 80-110 6.0 20
H22 100-135 5.5 16
H24 115-145 5.0 12
H26 125-160 4.0 8
H18 160 - 1



Produce capability:



Product Width(mm) Thickness(mm) O.D.(mm) Inside Diameters(mm)
Fin stock 60-1440 0.08-0.2 400-1400 75,150,200,300,400





2. Our advantage



1. Since 1988, we have rich experience in this industry in China;



2. Good reputation in Aluminum and Copper Areas;



3. We start our productions from aluminum ingot,so we can control the quality as well;



4. We have our own development department for new material research;



5. Good experience and cooperation with big client in the world;



6. With Certificate ISO9001-2008;



7. High performance cost ratio;



8. Fast delivery time;



9. Good communication skills, and good service and understandings for customers;.





3. Application:



Aluminum fin foil can be used in a variety of heat exchange constructions where the basic function is to efficiently transfer heat. Also this fin foil can be used for evaporator and condenser in most residential, automotive, and commercial air conditioning units. In addition, this foils are used in humidifiers, dehumidifiers, baseboard space heaters of various types, and other equipment.





4. Features:


Our fin foil is Halogen-free; so healthy environment for welder, it can be use for high temperature;
Besides, it can be used for different products & different Application like for weld backing; heat exchanger; air cooler material; air cooling fin; Air conditioning; Ducting; oil cooler; engineering machinery; Sealing & for Insulation purpose; etc;





Auto Air Conditioning Hard Tempered Aluminium Foil Alloy 1100 H18 100 - 135 MPa 0
