Hydrophilic Aluminium Foil Roll / Coil for Household Air Conditioning 0.17mm * 100mm

Hydrophilic Aluminium Foil Roll / Coil for Household Air Conditioning 0.17mm * 100mm
Hydrophilic Aluminium Foil Roll / Coil for Household Air Conditioning 0.17mm * 100mm Hydrophilic Aluminium Foil Roll / Coil for Household Air Conditioning 0.17mm * 100mm

Large Image :  Hydrophilic Aluminium Foil Roll / Coil for Household Air Conditioning 0.17mm * 100mm

Product Details:
Place of Origin: China
Brand Name: Trumony
Certification: ISO9001-2008
Model Number: TR-FS006
Payment & Shipping Terms:
Minimum Order Quantity: 5 metric tons
Price: negotiation
Packaging Details: Standard export packaging
Delivery Time: 30 working days after received your down payment
Payment Terms: T/T or LC
Supply Ability: 50,000 mt per year

Hydrophilic Aluminium Foil Roll / Coil for Household Air Conditioning 0.17mm * 100mm

Description
Alloy: 8011 Temper: HO
Thickness: 0.17mm Width: 100mm
I.D.: 75mm O.D.: 500mm Max
Rm(MPa): 100-135 A50(%): 16 Min
Cup Drawing Value(mm): 5.5 Min Other Requirements: According To Customers' Requests
High Light:

aluminum foil roll

,

aluminium foil packaging

0.17 x 100mm 8011 HO Customer-made Aluminum Fin Stock Coil for Household Air Conditioning





1. Description of our production



Our chemical composition:





Alloy

Si Fe Cu Mn Mg Zn Cr Ti code
8011 0.5-0.9 0.6-1.0 0.1 0.2 0.05 0.1 0.05 0.08 1
1100 0.95 0.05-0.2 0.05 -- 2
1200 1.00 0.05 0.05 0.05 3



Our mechanical property:



Temper

Tensile Strength

Rm(MPa)

Erichsen(mm) Elongation(%)
O 80-110 6.0 20
H22 100-135 5.5 16
H24 115-145 5.0 12
H26 125-160 4.0 8
H18 160 - 1



Produce capability:



Product Width(mm) Thickness(mm) O.D.(mm) Inside Diameters(mm)
Fin stock 60-1440 0.08-0.2 400-1400 75,150,200,300,400





2. Features:


Our fin foil is Halogen-free; so healthy environment for welder, it can be use for high temperature;
Besides, it can be used for different products & different Application like for weld backing; heat exchanger; air cooler material; air cooling fin; Air conditioning; Ducting; oil cooler; engineering machinery; Sealing & for Insulation purpose; etc;





3. Applications:



Aluminum fin foil can be used in a variety of heat exchange constructions where the basic function is to efficiently transfer heat. Also this fin foil can be used for evaporator and condenser in most residential, automotive, and commercial air conditioning units. In addition, this foils are used in humidifiers, dehumidifiers, baseboard space heaters of various types, and other equipment.





4. Our advantage



1. Since 1988, we have rich experience in this industry in China;



2. Good reputation in Aluminum and Copper Areas;



3. We start our productions from aluminum ingot,so we can control the quality as well;



4. We have our own development department for new material research;



5. Good experience and cooperation with big client in the world;



6. With Certificate ISO9001-2008;



7. High performance cost ratio;



8. Fast delivery time;



9. Good communication skills, and good service and understandings for customers;.
