Alloy 4343 / 3003 + 0.5% Cu / 5005 Aluminum Heat Transfer Sheets Moderate Strength

Name: Alloy 4343 / 3003 + 0.5% Cu / 5005 Aluminum Heat Transfer Sheets Moderate Strength
Brand: Trumony Aluminum Limited
SKU: TR- 4343/3003+0.5%Cu/5005
Availability: InStock

Basic Properties

Place of Origin: China

Brand Name: Trumony

Certification: ISO9001-2008

Model Number: TR- 4343/3003+0.5%Cu/5005

Trading Properties

Minimum Order Quantity: 5 Tons

Price: Negociable

Payment Terms: L/C, T/T

Supply Ability: 800,000 per a year

heavy duty aluminum foil

Specifications

Clad Layer:	4343 , 5005	Type:	Brazing
Application:	Radiator , Condenser , Cooling System	Size:	As Customer Request
Temper:	HO	Cladding Ratio:	4 - 8% For Each Side
Feature:	Moderate Strength
High Light:	aluminum sheet coil , aluminium foil strip

Product Description

Alloy 4343/3003+0.5%Cu/5005 Aluminum Heat Transfer Sheets With Moderate Strength For Radiator Heater Plates

Core Material

Alloy	Si	Fe	Cu	Mn	Mg	Zn	Zr	Ti	code
3003	0.6	0.7	0.05-0.20	1.0-1.5	－	0.1	0.05	0.03

Cladding Material

Alloy	Si	Fe	Cu	Mn	Mg	Zn	Zr	Ti	code
4343	6.8- 8.2	0.8	0.25	0.1	-	0.20	－	0.05

5005

0.3

0.7

0.2

0.5-1.1

0.5-1.0

0.03

Produce capability

	Width(mm)	Thickness(mm)	Length(mm)	Inside Diameters(mm)
Sheet	500-1070	0.5-5.0	500-2500	As customer request

Strength of Plates

Pre-Braze Strenght ( Mpa)

Post - Braze Strength ( Mpa )

Alloy

Temper

Yield Strength

Tensile Strength

Temsile Strength

Yield Strength

4343/3003+0.5%Cu/5005

> / = 45

120 -150

135

Our Advantage:

1. Manufacturer and Distributer, we can supply different brand and series plate and gasket,

2. As manufacturer, we can supply the best quality replace parts for above brands to help you save cost.

3. Over 10 years experience on the energy field, we also can provided technical service such as technical consultation, equipment update, capacity expansion scheme, maintenance and cleaning of the equipment.

4. ISO9001:2008 international quality standard certification.

5. One year lifetime guarantee.

6. High quality and competitive price , fast delivery.
