0.10 x 36mm Temper H14 Radiator Aluminium Thin Foil 3003 + 1.5% Zn

0.10 x 36mm Temper H14 Radiator Aluminium Thin Foil 3003 + 1.5% Zn
0.10 x 36mm Temper H14 Radiator Aluminium Thin Foil 3003 + 1.5% Zn 0.10 x 36mm Temper H14 Radiator Aluminium Thin Foil 3003 + 1.5% Zn 0.10 x 36mm Temper H14 Radiator Aluminium Thin Foil 3003 + 1.5% Zn

Large Image :  0.10 x 36mm Temper H14 Radiator Aluminium Thin Foil 3003 + 1.5% Zn

Product Details:
Place of Origin: China
Brand Name: Trumony
Certification: TS16949 , ISO14001 and OHSAS 18001
Model Number: TR-FR150
Payment & Shipping Terms:
Minimum Order Quantity: 5 metric tons
Price: negotiation
Packaging Details: Standard export packaging
Delivery Time: 30 working days after received your down payment
Payment Terms: T/T or LC
Supply Ability: 100,000 mt per year

0.10 x 36mm Temper H14 Radiator Aluminium Thin Foil 3003 + 1.5% Zn

Core Alloy: 3003+1.5%Zn Thickness: 0.1mm
Width: 36mm I.D.: 254mm
O.D.: ≤1500mm Packaging: Eye To Sky
Temper: H14
High Light:

aluminum foil roll


heavy duty aluminum foil

0.10 x 36mm 3003 + 1.5%Zn H14 Aluminum Non-clad Foil Roll for Radiator Fin



1. Description of our production


Chemical composition of core material, cladding material about aluminum alloy and composite-material for welding heat exchanger


1) Core Material


Alloy Si Fe Cu Mn Mg Zn Zr Ti code
3003 0.6 0.7 0.05-0.20 1.0-1.5 0.1 0.05 0.03 1
3003+1%Zn 0.6 0.7 0.05-0.20 1.0-1.5 0.5-1.50 0.05 0.05 2
3003+1.5%Zn 0.6 0.7 0.05-0.20 1.0-1.5 1.0-2.0 0.05 0.05 3
3003+1.5%Zn+Zr 0.5-1.0 0.7 0.05-0.20 1.0-1.6 1.0-2.0 0.05-0.2 - 4
3003+0.5%Cu 0.6 0.7 0.30-0.70 1.0-1.5 0.10 0.05 0.1 5
3005 0.6 0.7 0.20-0.40 1.0-1.5 0.20-0.60 0.25 0.01 6


2) Main mechanical of aluminum alloy and composite-material for welding heat exchanger


Alloy Code temper

Tensile Strength


Yield Strength Rp0.2(Mpa)

Extend Ratio


TR-010,TR-020,TR-030,TR-040,TR-050,TR-110,TR-310,TR-116,TR-316,TR-111,TR-313,TR-121,TR-131,TR-141,TR-150,TR-151,TR-156 Etc. O 95-135* ≥35* ≥15*
H14 140-185 ≥125 ≥1.5
H24 140-185 ≥125 ≥3.0
H16 185-225 ≥160 ≥1.0
H18 ≥185 - ≥0.5
TR-166 Etc.tube material H24 185-235 ≥150 ≥8

TR-116,TR-316 Etc.tube


H14 140-185 ≥125 ≥3
H24 140-185 ≥125 ≥8


Remark:“*”in the above file means the tensile strength will be 120-150Mpa,yield strength will be ≥45Mpa,and elongation will be ≥20% if the material of TR-050,TR-150,TR-151,TR-156 etc. with temper O contain Cu..


Additional: We can produce special specification according to customer’s request.


3) Produce capability


  Width(mm) Thickness(mm) Length(mm) Inside Diameters(mm)
Sheet 500-1070 0.5-5.0 500-2500 -
Strip 12-1070 0.2-3.0 - 150,200,300,400,500
Foil 12-1070 0.05-0.2 - 150,200,300,400,500


Composite ratio 4-18%(per side)


Percent Clad(per side) 4-8% > 8-18%
Cladding tolerance ±1.5% ±2.0%



2. Applications:


We dedicated to the production of clad and unclad aluminum materials for braze-type automobile heat exchangers like radiator, intercooler, condenser, evaporator and industrial heat exchangers, like air coolers for power plants, air conditioner etc.and other aluminum alloy products.



3. Features


Uncladded/Cladded aluminum material is suitable for a variety of brazing processes, such as Nocolok brazing and vacuum brazing, It’s widely used in engine cooling and air conditioner systems in automotive industry; such as radiator;condenser;evaporator;intercooler; oil cooler and heater; In home electrics industries;such as HVAC heat exchanger; water heater;PTC heating unit; In the industrial field;such as power plant cooling systems;construction machinery and air separation equipment; Our cladded aluminum material highly recommended in the market for its stable mechanical properties;stable cladded percentage and excellent corrosion resistance.



4. F&Q


1, Q: Are you manufacturer?

A: Yes, we are established in 2003. As a manufacturer our customers are welcome to visit our factory.


2, Q: Do you accept customized orders?

A: Yes, we do. Your customized orders are always welcomed. Please kindly offer us your technical perfrmances or samples so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.


3. Q: How can I get one quotation faster?

A: Pls offer details about your demands as more as possible,insulation thickness,over diameter,nominal voltage,working temperature,color,quantity,application,etc.


4, Q: What's your MOQ?

A: Normally 5 metric tons are requested as the minimum order quantity on our side.


5, Q: What's your payment term?

A: 30% deposit in advance via T/T,balance before shipment.
