|Alloy:||1000 Series , 3000 Series , 5000 Series||Temper:||H44 , H46 , H48|
|Thickness:||0.2 ~ 1.5 Mm||Front Side:||PE , Alu Eciling Face - Paint , PVDF|
|Back Side:||Mill Finish|
aluminium sheet coil
Colorful Aluminium Color Coated Coil For Ceilings Usage
Quick Details ;
1 , Products : Aluminum Color Coated Coil & Sheets
2 , Alloy : 1000 series , 3000 Series , 5000 series
3 , Aluminum Thickness (mm) : 0.2 ~ 1.5 mm
4 , Temper : H44 , H46 , H48 ,
5 , Dry Coating Thickness : Top Coating : 8 ~ 22 um ; Pros and cons single bottom coating : 7 ~ 20
6 , Width : 700 ~ 1600 mm
7 , Coil wight : < / = 5000 kg
8 , I D : 405 mm , 505 mm
Remarks : 1 . The alloy , temper & size can be negotiated by buyer and seller
2 , Width can be 50 ~ 800mm as per customer's requirement.
Coating Characteristic Table
|Inspection items||Coating Types|
|PVDF||PE||Ceiling Top Lacquer|
|No natural clear lacquer||With natural clear lacquer|
|Coating Thickness||26 + /-1||18 + / - 1||20 + / - 1|
|Glossy Tolerance||60O glossy value ≥ 80 unit , tolerance + / - 10 unit||glossy value ≥ 80 unit , tolerance + / - 10unit|
|60O glossy value ≥ 20 ~ 80 unit , tolerance + / - 7 unit||glossy value≥20 ~ 80 unit , tolerance + / - 7 unit|
|60O glossy value >20 unit , tolerance + / - 5unit||60O glossy value >20 unit , tolerance + / - 5unit|
|Pencil Hardness||≥ IH||≥ 2H||≥2H|
|Impact Resistance||No failing , No crack||No failing , No crack|
|Adhesive Quality||0 grade and 1 grade||0 grade and 1 grade|
|Acid Resistance||No Change||Coating no change|
|Solventresistance||Bottom not appearance after 100 times||Bottom not appearance after 100 times||Bottom not appearance after 100 times||Bottom not appearance after 100 times|
|Color Difference||The coating color is almost same as confirmed by buyer and seller , the color difference tested by colorimeter between single coating and sample is less tan 1.2 , same lot products color difference|
Introduction of Products
Aluminum Color Coated Coil produced by nice coated equipment, advantaged technology , coated by various color and different thickness , appearance colorful and shining products.
The products mainly used to produce aluminum composite panels , aluminum single sheet, aluminum beehive sheets, veined coating aluminum coil and mainly used in aluminum rooler shutter and roller blinds , aluminum ceiling , aluminum door and widows, scan sign , decorating car , boat , aluminum container, home appliances , kitchen ware and cabinet, control panel , light - fixture , furniture sun power reflector panel and so on .
Cood Weathering : Choosing different coating materials as per using environment, the coating is hardness and slick , ater - resistance , sovle - resistance , anti-washing , long ages, Especially for PVDF materials , it has good weather resistance to use for decorating wall and special place for more than 20 years under bad whether .
Colorful : Different materials and color appearances top grade floweriness .
Recycling : it can be recycling , no depreciation , high.
Saving energy : aluminum is containing electric and energy itself , 95 % can be recycled used, less depreciation.
Customer provides sample or color card and code -- Painter matches the color as per the sample -- Coating and getting sampl -- Customer confirms the sample
Mill Finish Aluminum Coil comfirmation
Customer provides technical standard --- Technology confirms to meet the technical requirement
Above two confirmed , arranging production as per order
