Bottle Caps Color Coated Aluminum , Mill Finish Coil Aluminium Sheet Roll

MOQ:	5 Ton
Price:	Negotiation
Standard Packaging:	Standard Export Packages
Delivery Period:	30 Working days
Supply Capacity:	800,000 Per Year

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Trumony

Certification

ISO9001-2008

Model Number

TR-1000

Alloy:

1000 Series , 3000 Series , 5000 Series

Temper:

H14 , H16

Thickness:

0.15 - 0.7mm

Width:

30 - 1000mm

Back Side:

Mill Finish

Highlight:

aluminum sheet roll

aluminium sheet coil

Product Description

Colorful Aluminium Color Coated Coil For Ceilings Usage

Quick Details ;

1 , Products : Aluminum Color Coated Coil & Sheets

2 , Alloy : 1000 series , 3000 Series , 5000 series

3 , Aluminum Thickness (mm) : 0.2 ~ 1.5 mm

4 , Temper : H44 , H46 , H48 ,

5 , Dry Coating Thickness : Top Coating : 8 ~ 22 um ; Pros and cons single bottom coating : 7 ~ 20

Remarks : 1 . The alloy , temper & size can be negotiated by buyer and seller

2 , Width can be 50 ~ 800mm as per customer's requirement.

Coating Characteristic Table

Inspection items	Coating Types
	PVDF	PE	Ceiling Top Lacquer
			No natural clear lacquer	With natural clear lacquer
Coating Thickness	26 + /-1	18 + / - 1	20 + / - 1
Glossy Tolerance	60^Oglossy value ≥ 80 unit , tolerance + / - 10 unit		glossy value ≥ 80 unit , tolerance + / - 10unit
	60^Oglossy value ≥ 20 ~ 80 unit , tolerance + / - 7 unit		glossy value≥20 ~ 80 unit , tolerance + / - 7 unit
	60^Oglossy value >20 unit , tolerance + / - 5unit		60^Oglossy value >20 unit , tolerance + / - 5unit
Pencil Hardness	≥ IH	≥ 2H	≥2H
Flexible	≤2T	≤3T	≤2T
Impact Resistance	No failing , No crack		No failing , No crack
Adhesive Quality	0 grade and 1 grade		0 grade and 1 grade
Acid Resistance	No Change		Coating no change
Alkalistability	No change		-
Solventresistance	Bottom not appearance after 100 times	Bottom not appearance after 100 times	Bottom not appearance after 100 times	Bottom not appearance after 100 times
Color Difference	The coating color is almost same as confirmed by buyer and seller , the color difference tested by colorimeter between single coating and sample is less tan 1.2 , same lot products color difference

Characteristics

Cood Weathering : Choosing different coating materials as per using environment, the coating is hardness and slick , ater - resistance , sovle - resistance , anti-washing , long ages, Especially for PVDF materials , it has good weather resistance to use for decorating wall and special place for more than 20 years under bad whether .

Colorful : Different materials and color appearances top grade floweriness .

Recycling : it can be recycling , no depreciation , high.

Saving energy : aluminum is containing electric and energy itself , 95 % can be recycled used, less depreciation.

Order Procedure

Color Comfirmation

Customer provides sample or color card and code -- Painter matches the color as per the sample -- Coating and getting sampl -- Customer confirms the sample

Mill Finish Aluminum Coil comfirmation

Customer provides technical standard --- Technology confirms to meet the technical requirement

Above two confirmed , arranging production as per order
