Product Details:
|
Core Alloy: | 3003/3003+1.5%Zn+Zr/3005 | Clad Alloy: | 4343/4045 |
---|---|---|---|
Thickness: | 0.08mm/0.06mm/0.1mm Or As Per Customers' Requirement | Width: | 17mm/22mm/26mm Or As Per Customers' Requirement |
I.D.: | 200mm/254mm/300mm/500mm | O.D.: | 1500mm Max |
Packaging: | Eye To Wall | Temper: | HO/H14/H16/H18/H14SR |
Application: | Radiator/condenser/evaporator/intercooler/oil Cooler/heater | ||
Highlight: | aluminum sheet coil,aluminium foil strip |
0.08 x 17mm 4343/3003+1.5%Zn+Zr/4343 H16 Aluminum Brazed Foil for Auto Condenser Fin
1. Description of our production
Chemical composition of core material, cladding material about aluminum alloy and composite-material for welding heat exchanger
1) Core Material
Alloy | Si | Fe | Cu | Mn | Mg | Zn | Zr | Ti | code |
3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | - | 0.1 | 0.05 | 0.03 | 1 |
3003+1%Zn | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | - | 0.5-1.50 | 0.05 | 0.05 | 2 |
3003+1.5%Zn | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | - | 1.0-2.0 | 0.05 | 0.05 | 3 |
3003+1.5%Zn+Zr | 0.5-1.0 | 0.7 | 0.05-0.20 | 1.0-1.6 | - | 1.0-2.0 | 0.05-0.2 | - | 4 |
3003+0.5%Cu | 0.6 | 0.7 | 0.30-0.70 | 1.0-1.5 | - | 0.10 | 0.05 | 0.1 | 5 |
3005 | 0.6 | 0.7 | 0.20-0.40 | 1.0-1.5 | 0.20-0.60 | 0.25 | - | 0.01 | 6 |
2) Cladding Material
Alloy | Si | Fe | Cu | Mn | Mg | Zn | Zr | Ti | code |
4343 | 6.8-8.2 | 0.8 | 0.25 | 0.1 | - | 0.2 | - | 0.05 | 1 |
4343+1%Zn | 6.8-8.2 | 0.8 | 0.25 | 0.1 | - | 0.5-1.5 | - | 0.05 | 2 |
4045 | 9.0-11.0 | 0.8 | 0.3 | 0.05 | - | 0.2 | - | 0.2 | 3 |
4045+1%Zn | 9.0-11.0 | 0.8 | 0.3 | 0.05 | - | 0.5-1.5 | - | 0.2 | 4 |
4004 | 9.0-10.5 | 0.8 | 0.25 | 0.1 | 1.0-2.0 | 0.2 | - | 0.2 | 5 |
7072 | 0.7 | 0.1 | 0.1 | 0.1 | 0.8-1.3 | - | - | 6 | |
5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5-1.1 | 0.5-1.0 | - | 0.03 | 7 |
3) Main mechanical of aluminum alloy and composite-material for welding heat exchanger
Alloy Code | temper |
Tensile Strength Rm(MPa) |
Yield Strength Rp0.2(Mpa) |
Extend Ratio A50(%) |
TR-010,TR-020,TR-030,TR-040,TR-050,TR-110,TR-310,TR-116,TR-316,TR-111,TR-313,TR-121,TR-131,TR-141,TR-150,TR-151,TR-156 Etc. | O | 95-135* | ≥35* | ≥15* |
H14 | 140-185 | ≥125 | ≥1.5 | |
H24 | 140-185 | ≥125 | ≥3.0 | |
H16 | 185-225 | ≥160 | ≥1.0 | |
H18 | ≥185 | - | ≥0.5 | |
TR-166 Etc.tube material | H24 | 185-235 | ≥150 | ≥8 |
TR-116,TR-316 Etc.tube material |
H14 | 140-185 | ≥125 | ≥3 |
H24 | 140-185 | ≥125 | ≥8 |
Remark:“*”in the above file means the tensile strength will be 120-150Mpa,yield strength will be ≥45Mpa,and elongation will be ≥20% if the material of TR-050,TR-150,TR-151,TR-156 etc. with temper O contain Cu..
Additional: We can produce special specification according to customer’s request.
4) Produce capability
Width(mm) | Thickness(mm) | Length(mm) | Inside Diameters(mm) | |
Sheet | 500-1070 | 0.5-5.0 | 500-2500 | - |
Strip | 12-1070 | 0.2-3.0 | - | 150,200,300,400,500 |
Foil | 12-1070 | 0.05-0.2 | - | 150,200,300,400,500 |
Composite ratio | 4-18%(per side) |
Percent Clad(per side) | 4-8% | > 8-18% |
Cladding tolerance | ±1.5% | ±2.0% |
2. Application:
We are dedicated to the production of clad and unclad aluminum materials for braze-type automobile heat exchangers like radiator, intercooler, condenser, evaporator and industrial heat exchangers, like air coolers for power plants, air conditioner etc.and other aluminum alloy products.
3. FAQ:
1, Q: Are you manufacturer?
A: Yes, we are established in 1988. As a manufacturer our customers are welcome to visit our factory.
2, Q: Do you accept customized orders?
A: Yes, we do. Your customized orders are always welcomed. Please kindly offer us your technical perfrmances or samples so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.
3. Q: How can I get one quotation faster?
A: Pls offer details about your demands as more as possible, alloy, temper, thickness, width, quantity,application,etc.
4. Q: If I can not offer above information,what should I do?
A: Try your best to offer more information,we will help you design suitable material.
5. Q: What is your company sample policy?
A: As one supplier,we see that sample is necessary for our both sides, our policy is to offer samples as possible as we can, About sample shippment,you need to pay for the freight,usually freight collect by express.
